2017 New Design Excellent Quality hand operated coconut oil expeller
Agriculture & Food Agricultural Equipment
MOQ:1 Set(s)
Payment Method : L/C T/T Others
Keywords:oil expeller
| Product Category: | Agriculture & Food > Agricultural Equipment | Trademark: | |
| Product Package: | Specifications: | ||
| Place of Origin: | Port: | hebei |
Model | YS200A-3 |
Matching | 18.5 kw |
Processing capacity | Pressinng 6.5-10 ton per day |
Weight(g.W/N.W) | 5000kg |
Dimensions | 2850×1850×3270mm |
Material | Alloy steel/ cast stee |
Steaming and frying temperature | 125-128℃ |
Packing | Wooden cases |
Cake residue oil rate | 5%-7.5% |
Inquiry | Your Quality? Your Capacity? Your Length? |
Usage
This oil press machine is suitable for the extraction of vegetable oils from such oil-bearing materials as rape seed,peanuts,sesame seed,etc.(The pressing worms can be replaced as required by the user for the purpose of the extraction of oils from some other oil-bearing materials,such as rice bran oil and the like.)
Features
1 All such main parts of this oil press machine as worm shaft ,pressing worms,cage and so forth are made of high-grade alloy steel through hardening treatment.As a result,in spite of the conditions of high temperature and abrasion under which they work day and night,they keep durable for a considerable period.
2 The combination of steaming and roasting is also one of the features of this machine.It can be regulated in accordance with the varied requirements of various oil-bearing materials for the temperatures pressing so as to get high quality oils.
3 The whole process form feeding,steaming,roasting up to the discharge of oil and cake of this oil press goes on automatically and continuously,so it is easy to operate the machine,which results in the saving of labor.
Main technical parameters
1, Capacity(The Treating Capacity For Seeds)
Name | of oil | Capacity(kg/24hrs) | Oil yield(%) | Residual oil in dry |
seed | cake(%) | |||
Rape seed | 9000-12000 | 33-38 | 6-7 | |
Prsnuts | 9000-10000 | 38-45 | 5-6 | |
Sesame seed | 6500-7500 | 42-47 | 7-7.5 | |
Cotton beans | 9000-10000 | 30-33 | 5-6 | |
Soya beans | 8000-9000 | 11-14 | 5-6 | |
Sunflower | 7000-8000 | 22-25 | 6-7 | |
seed | ||||
Rice bran | 6000-7000 | 10-14 | 6-7 | |
2, | Inside diameter of steaming kettle: 1200mm | |||
3, | Stirring shaft speed :35rpm | |||
4, | Steam pressure 5-6kg/ cm | |||
5, | Pressing bores:Front section 180mm | |||
Rear section 152mm | ||||
6, | Pressing worm speed :8rpm | |||
7, | Feed shaft speed:69rpm | |||
8, | Pressing time in cage :2.5min | |||
9, | Seed steaming and roasting time :90min | |||
10, | Max.temperature for seed steaming and roasting:125-128℃ | |||
11, | Power demand:18.5kw | |||
12, | Overall dimensions(L*W*H):2850*1850*3270mm | |||
