High quality China supplier solar street light 40W

JIANGSU QICHUANG PHOTOELECTRIC GROUP CO.,LTD.

Business Type:Manufacturer

Main Products: LightingHoliday LightingAuto Lighting Accessories

view on mobile

High quality China supplier solar street light 40W

Furniture,Lights & Construction

FOB Price:US$ 280.00 / Piece(s)

MOQ:100 Piece(s)

Payment Method : T/T

Keywords:Solar street lamp

Inquire

Add to Favorites

Product Category:	Furniture,Lights & Construction >	Trademark:
Product Package:		Specifications:
Place of Origin:		Port:	guangzhou

Overview

Quick Details

Light Source:
LED

Input Voltage(V):
DC12/24V

Lamp Luminous Flux(lm):
3000

CRI (Ra>):
75

Working Temperature(℃):
-40 - 60

Working Lifetime(Hour):
50000

IP Rating:
IP65

Certification:
CCC, CE, CQC, RoHS

Warranty(Year):
3~5years

Place of Origin:
Jiangsu, China

Brand Name:
QiChuang

Model Number:
QC-SSL-001

Application:
LANDSCAPE, Highway/Road/Street/Square/Garden

Power Supply:
DC

Light type:
LED

Lamp Luminous Efficiency(lm/w):
150

Color Temperature(CCT):
3000K-6500K

Lamp Body Material:
Die-casting aluminum

Keyword:
solar street light

Material:
Die-casting aluminum+Glass Cover

Waterproof:
Yes

Item:
Within 15days

Lead time for bulk order:
About 20~30days, according to the order quantity

Product Certification

CE Certified.
Valid from 2017-09-26 until 2049-12-31

Supply Ability

Supply Ability:
10000 Set/Sets per Month solar street light

Packaging & Delivery

Packaging Details
LED Lamp: Carton packaging;
Solar Panel: Carton and pallet packaging;
Solar Battery: Carton and pallet packaging;
Pole and Brackets: Cotton wrap

Port
Shanghai port/Ningbo port

Lead Time :
Quantity(Sets) 1 - 100 101 - 500 >500
Est. Time(days) 20 25 To be negotiated

Product Description

Lamp Specifications:

Max Power	20W/30W/40W/50W/60W
LED driver	MEANWELL/..../ZHIHE
LED chip	Lumileds 3030/BRIDGELUX/EPRISTAR/CREE
Material	Die-casting aluminum+Glass Cover
Light Luminous Efficiency	>150 lm/W
Uniformity	>0.8
Average illumination	6m>25LUX 8m>20LUX
LED Luminous Efficiency	>90%
Color temperature	3000-6500K
Color Rendering index	Ra>75
Input Voltage	DC12/24V
Power Efficiency	>90%
Power Factor	>0.95
Working environment	-40℃~60℃
IP rating	IP65
Working life	>50000hours
Warranty	5years
Size	48520050mm
Wight	2kg

	LED lamp
	1.High power LED light source with more than 80000 hours lifetspan
	2.White color,150lm/w,30Lux,6500K, IP65,120 degree angle
	3.Lamp housing:die-casting aluminum+glass cover+IP65,lifespan:more than 20 years
	4.Over-charging/discharging protection, reverse-connection protection

	Solar panel
	1.Monocrystalline solar panel 30W-310W, efficiency of more than 18.5%
	2.Polycrystalline solar panel 30W-270W, efficiency of more than 17.8%
	3.Aluminum frame, tempered glass.
	4.5 years warranty for solar panels; 20 years power generation capacity

	Storage and controlling lithium battery
	1.Long service lifespan:charge and discharge cycle over 1500 times.
	2.Fast charging speed: it is the 1.5times than the normal battery.
	3.High depth-of-discharge: depth-of discharge of 95% (DOD of 95%).
	4.Large battery capacity: storage battery is 5 times than the normal battery.
	5.Intelligent system: the LED source, solar panel,lithium battery reasonable allocated by the lithium battery system to reduce the energy loss.
