Min/Min Platform Length

4/10m

11/30m

Max Load Capacity

2000/1500 kg

3600/2000kg

Lifting Speed

0~6m/min

0~6m/min

Maximum Lifting Height

200m

200m

Tie-in Interval

7.5m

7.5m

Free Standing Height when working

6 m

6 m

Free Standing Height when erecting

15 m

15 m

Max Wind Speed Allowed for Working

12.7m/s

Max Wind Speed Allowed for Erection

6 m/s

Dimensions & Weight

Platform Section Size

1.5m×1.35m×0.65m

1.5m×1.35m×0.65m

Telescopic Platform max Extension

0.9m

0.9m

Platform Weight

115kg

115kg

Mast Section Size

0.5m×0.5m×1.508m

0.5m×0.5m×1.508m

Weight of Normal Mast Section

80kg

80kg

Weight of Thickened Mast Section

106kg

106kg

Weight of Transit Mast Section

Weight of Base Unit

526kg

526kg

Weight of Driving Unit

91kg

91kg

Electrical Parameters

Driving System

2.2kw×2

2.2 kw×2 +2.2 kw×2

Voltage / Frequency

380V/50Hz

380V/50Hz

Control Voltage / Frequency

24V/50Hz

24V/50Hz

Starting Current

16.5A

33A

Working Current

11A

22A
