Tbyl Series Three-Phase Asynchronous Electric\/Electrical AC Motor

Tbyl Series Three-Phase Asynchronous Electric/Electrical AC Motor

Auto,Parts & Accessories Automotive & Parts

FOB Price:US$ 57.00 / Piece(s)

MOQ:1 Piece(s)

Payment Method : L/C T/T

Keywords:Tbyl Series Three-Phase Asynchronous Electric Electrical AC Moto

Inquire

Add to Favorites

Product Category:	Auto,Parts & Accessories > Automotive & Parts	Trademark:
Product Package:		Specifications:
Place of Origin:		Port:	Xiamen

Basic Info.

Model NO.

TBYL

Number of Poles

2, 4, 6

Starting Mode

Variable Frequency Starting

Certification

ISO9001, CCC

Brand

Tongbo

Rated Frequency

50Hz, 60Hz

Rated Voltage

380V or Any Voltage Between 220V-760V

Protection Class

IP44, IP54, IP55

Cooling Method

IC0141

Duty

S1(Continuous)

Origin

Fujian, China

HS Code

8501520000

Product Description

Customer Question & Answer

Introduction:
TBYL series three-phase induction motors, developed with new techniques, are renewal and upgrading products of Y series.
TBYL series motors are defined as totally enclosed, fan cooled, squirrel cage type and noted for their novel design, beautiful modelling, compact structure, low noise, high efficiency, large torque, excellent starting performance, easy service, etc. The motors are
Adopted with F class insulation and designed with assessing method for insulation system according to international practice, it enhances greatly safety and reliability of motors.
TBYL series motors can be widely used as driving equipment of various machineries, same as, machine tools, blowers, pumps, compressors, transporters, agricultural and food processing.
Operating conditions:
Ambient temperature:-15oC<θ<40oC
Altitude: not exceed 1000m
Rated voltage:380V or any voltage between 220V-760V
Rated frequency: 50Hz,60Hz
Protection class:IP44,IP54,IP55
Insulation class: B,F
Cooling method: IC0141
Duty:S1(continuous)
Connection: Star-connection for up to 3kW,
Delta-connection for 4kW and above.
Technical Data:

Model	Output		Speed(r.p.m)	Eff.(%)	Power factor (cos<p)	Rated current(A)			Rated Torque Num	lst/ln	Tst/Tn
Model	KW	HP	Speed(r.p.m)	Eff.(%)	Power factor (cos<p)	380	400	415	Rated Torque Num	lst/ln	Tst/Tn
SPEED 3000RPM 2-POLE 50HZ
TBYL-801-2	0.75	1	2875	77.4	0.83	1.77	1.68	1.62	2.49	5.30	2.5	3
TBYL-802-2	1.1	1.5	2875	79.6	0.84	2.50	2.37	1.29	3.65	7.00	3.2	3.8
TBYL-90S-2	1.5	2	2890	81.3	0.84	3.32	3.16	3.04	4.96	7.10	2.7	3.5
TBYL-90L-2	22	3	2890	83.2	0.85	4.72	4.48	4.32	7.27	6.90	2.4	3
TBYL-100L-2	3	4	2891	84.6	0.87	6.17	5.86	5.65	9.91	8.00	3.2	4
TBYL-112M-2	4	5.5	2914	85.8	0.88	8.04	7.64	7.36	13.11	7.50	2.5	3
TBYL-132S1-2	S.S	7.5	2937	87.0	0.86	11.2	10.6	10.2	17.88	7.50	2.7	3.5
TBYL-132S2-2	7S	10	2940	88.1	0.88	14.6	13.9	13.4	24.36	7.50	2.4	3.3
TBYL-1601-2	11	15	2930	89.4	0.89	21.0	19.9	19.2	35.85	7.60	2.2	2.9
TBYL-160M2-2	15	20	2930	90.3	0.89	28.4	26.9	26.0	48.89	7.60	2.3	3
TBYL-160L-2	18.5	25	2937	90.9	0.89	34.7	33.0	31.8	60.15	7.40	2.3	3.1
TBYL-180M-2	22	30	2940	91.3	0.88	41.6	39.5	38.1	71.46	7.80	2.8	3.2
TBYL-200L1-2	30	40	2950	92.0	0.88	56.2	53.4	51.5	97.12	7.80	2.6	3
TBYL-200L2-2	37	50	2950	92.5	0.89	68.2	64.8	62.5	119.78	7.70	2.6	3
TBYL-225M-2	45	60	2960	92.9	0.89	82.5	78.4	75.6	145.19	7.50	2.4	2.6
TBYL-250M-2	55	75	2965	93.2	0.90	99.5	94.5	91.1	177.15	7.10	2.3	2.8
TBYL-280S-2	75	100	2970	93.8	0.90	135	128	123	241.16	7.40	2.5	2.8
TBYL-280M-2	90	125	2970	94.1	0.91	160	152	146	289.39	7.60	2.8	2.8
TBYL-315S-2	110	150	2975	94.3	0.91	194	185	178	353.11	6.90	24	2.8
TBYL-315M-2	132	180	2975	94.6	0,91	233	221	213	423.73	7.10	2.6	2.9
TBYL-315L1-2	160	200	2975	94.8	0.92	278	265	255	513.61	7.10	2.5	2.9
TBYL-315L2-2	200	270	2975	95.0	0.92	348	330	318	642.02	6.90	2.5	2.8
TBYL-355M-2	250	340	2980	95.0	0.92	434	412	398	801.17	7.00	2.5	2.8
TBYL-355L-2	315	430	2980	95.0	0.92	547	520	501	1009.48	7.00	2.5	2.9
SPEED 1500RPM 4-POLE 50HZ
TBYL-802-4	0.75	1	1400	79.6	0.76	1.88	1.79	1.72	5.12	5	2.4	2.9
TBYL-90S-4	1.1	1.5	1440	81.4	0.77	2.66	2.53	2.44	7.3	6	3	3.5
TBYL-90L-4	1.5	2	1445	82.8	0.77	3.57	3.39	3.27	9.91	6.8	3.2	3.8
TBYL-100L1-4	2.2	3	1440	84.3	0.81	4.88	4.64	4.47	14.6	7	3	3.5
TBYL-100L2-4	3	4	1140	85.5	0.82	6.50	6.18	5.95	19.9	7S	2.6	33
TBYL-112M-4	4	5.5	1445	86.6	0.82	8.55	8.12	7.83	26.4	7	3.5	4
TBYL-1 B2S-4	5.5	7.5	1455	87.7	0.83	11.5	10.9	10.5	36.1	6.4	2.2	2.8
TBYL-132M-4	7.5	10	1455	88.7	0.84	15.3	14.5	14.0	49.2	7	2.4	3
TBYL-160M-4	11	15	1460	89.8	0.84	22.1	21.0	20.3	71.9	6.9	2.5	2.9
TBYL-160L-4	15	20	1460	90.6	0.85	29.6	28.1	27.1	98.1	7.5	2.5	3
TBYL-180M-4	18.5	25	1470	91.2	0.86	35.8	34.0	32.8	120.2	7,8	2.6	3.1
TBYL-180L-4	22	30	1470	91	0.86	42.3	40.2	38.7	142.9	7.5	2.2	2.3
TBYL-200L-4	30	40	1470	92.3	0.86	57.3	54.4	52.5	194.9	7.1	2.4	2.9
TBYL-225S-4	37	50	1480	92.7	0.87	69.7	66.2	63.8	238.8	7.5	2.5	2.7
TBYL-225M-4	45	60	1480	93.1	0.87	84.3	80.1	77.2	290.4	7.6	2.5	2.8
TBYL-250M-4	55	75	1480	93.5	0.87	103	97.5	94	354.9	7.3	2.6	2.7
TBYL-280S-4	75	100	1480	94.0	0.87	139	132	127	484	7.6	2.7	2.7
TBYL-280M-4	90	125	1480	94.2	0.87	167	158	153	580.7	7.5	2.7	2.7
TBYL-315S-4	110	150	1485	94.5	0.88	201	191	184	707.4	7.1	2.7	2.9
TBYL-315M-4	132	180	1485	94.7	0.88	240	228	220	88.9	7.3	27	2.9
TBYL-315L1-4	160	200	1485	94.9	0.89	288	273	263	1029	7.4	3	3
TBYL-315L2-4	200	270	1485	95.1	0.89	359	341	B28	1286	7.6	3	3
TBYL-355M-4	250	340	1490	95.1	0.90	443	421	406	1602	7.5	2.8	2.9
TBYL-355L-4	315	430	1490	95.1	0.90	559	531	511	2019	7.4	2.6	2.8
SPEED 1000RPM 6-POLE 50HZ

TBYL-90S-6	0.75	1	934	75.9	0.72	2.08	1.98	1.9	7.67	4.5	2.2	2.4
TBYL-90L-6	1.1	1.5	945	78.1	0.72	2.97	2.82	2.72	11.1	4.5	2.4	2.6
TBYL-100L-6	1.5	2	945	79.8	0.75	3.8	3.61	3.48	15.2	4.2	1.8	2.2
TBYL-112M-6	2.2	3	960	81.8	0.76	5.37	5.1	4.92	21.9	4.5	2.3	2.8
TBYL-132S-6	3	4	964	83.3	0.76	7.19	6.8B	6.58	29.7	4.5	1.8	2.4
TBYL-132M1-6	4	5.5	965	84.6	0.76	9.43	8.96	8.63	39.6	5.0	2.3	2.7
TBYL-132M2-6	5.5	7.5	965	96	0.77	12.6	12	11.5	54.4	5.5	1.9	2.8
TBYL-160M-6	7.5	10	970	87.2	0.78	16.7	15.9	15.3	73.8	6.5	2	3
TBYL-160L-6	11	15	970	88.7	0.78	24.1	22.9	22.1	108.3	7.5	2.4	3.3
TBYL-180L-6	15	20	975	89.7	0.81	31.4	29.8	28.7	146.9	6.4	2	2.7
TBYL-200L1-6	18.5	25	980	90.4	0.81	38.3	36.4	35.1	180.3	7	2.3	3
TBYL-200L2-6	22	30	980	90.9	0.83	44.3	42	40.5	214.4	7	2.3	2.8
TBYL-225M-6	30	40	980	91.7	0.84	59.2	56.2	54.2	292.3	6.5	2.2	2.7
TBYL-250M-6	37	50	980	92.2	0.86	70.8	67.3	64.8	360.6	6.9	2.5	2.7
TBYL-280S-6	45	60	980	92.7	0.86	85.8	81.5	78.5	438.5	7	2.2	2.4
TBYL-280M-6	55	75	980	93.1	0.86	104	99.2	95.6	536	7.1	2.4	2.5
TBYL-315S-6	75	100	985	93.7	0.86	141	134	129	727.2	7.3	2.8	3
TBYL-315M-6	90	125	985	94	0.86	169	160	155	872.6	7.1	2.7	2.9
TBYL-315L1-6	110	150	985	94.3	0.86	206	196	189	1066	7.4	2.9	2.9
TBYL-315L2-6	132	180	985	94.6	0.87	243	231	223	1280	7.6	3	3.1
TBYL-355M1-6	160	200	990	94.8	0.88	291	277	267	154B	7.6	3.1	3.1
TBYL-355M2-6	200	270	990	95	0.88	363	345	333	1929	7.8	3	3
TBYL-355L-6	250	340	990	95	0.88	454	432	416	2412	7.7	3.1	3
