Yzr Slip Ring Electric Motor for Crane

Yzr Slip Ring Electric Motor for Crane

Auto,Parts & Accessories Automotive & Parts

FOB Price:US$ 340.00 / Piece(s)

MOQ:1 Piece(s)

Payment Method : L/C T/T Wesstern Union

Keywords:Electric Motor Crane Slip Ring

Inquire

Add to Favorites

Product Category:	Auto,Parts & Accessories > Automotive & Parts	Trademark:
Product Package:		Specifications:
Place of Origin:		Port:	shanghai

Basic Info.

Model NO.

YZR

Starting Mode

Direct on-line Starting

Certification

CE, ISO, CCC

Brand

Pinnxun

Type

Slip Ring Crane Motor

Protect Feature

Enclosed

Structure

Asynchronous Motor

Phase

Three Phase

Color

Grey or Other

Shape

Linear

Scope of The Center Height

H112~H355

Work Mode

S1

Protection Class

IP55

Insulation Class

F

Trademark

pinnxun

Specification

YZR

Origin

China

HS Code

8501530090

Product Description

Customer Question & Answer

YZR,YZ series metallurgical and crane ac induction motor

1.General
    1.1  YZR and YZ series wound rotor and squirrel-cage rotor three-phase asynchronous motor for lifting and metallurgy is suitable for the power drive of the lifting machine and other similar equipment, with high overload capability and mechanical strength, and it is also suitable for short-time or intermittent character of service, the equipment with frequent starting, braking and obvious shock and impact.
1.2 The power grade and the installation dimensions of the motor are in accordance with the recommended standard of IEC 72; the correlation between the power grade and the installation dimensions is similar with Japan JEM1202 and Germany DIN42681, most of which can be exchanged. YZR series wound rotor three-phase asynchronous motor for metallurgy and lifting is in accordance with the specification of professional standard JB/T10105-1999 and YZ series squirrel-cage rotor three-phase asynchronous motor for metallurgy and lifting is in accordance with the professional standard.
2. Operation condition
The motor can run normally when the elevation not more than 1000m. The environment temperature for  class F is from -20 to 40 Celsius degree,for H class from -20 to 60 Celsius degree. Relative humidity less 90%.

3.Basic mode
rated voltage : 380V        rated frequency: 50HZ.
protection grade : IP44 or IP54    insulation level: F or H
cooling mode: IC410 or IC411
base operating duty:S3-40%
installation mode of the motor : B3(112-450),B5(112-250),V1(112-315)
  Note: the following are optional: over-temperature protection, dampproof heating belt, electromagnetism brake, coder, overspeed switch.

Model Explanation

Company Information

Packing & Shipping

Our Servies

WE ARE READY

Q: Do you offer OEM service?

A: Yes.

Q: What is your payment term?

A: 30% T/T in advance, 70% before delivery. Or irrevocable L/C.

Q: What is your lead time?

A: About 10-45 days after receiving deposit or original L/C.

Q: What certifiicate do you have?

A: We have CE, ISO,CCC and so on.

WHY CHOOSE US

WHAT WE DO AT PINNXUN

Stamping of lamination
Rotor die-casting
Winding and inserting - both manual and semi-automatically
Vacuum varnishing
Machining shaft, housing, end shields, etc
Rotor balancing
Painting - both wet paint and powder coating
Motor assembly
Packing
Inspecting spare parts every processing
100% test after each process and final test before packing.

Working	S2								S3
Working	S2								6/ 6times/hour
FC	30 30minutes				60 60minutes				15%				25%				40%
item	Pn Kw	I1 A	I2 A	n r/min	Pn Kw	I1 A	I2 A	n r/min	Pn Kw	I1 A	I2 A	n r/min	Pn Kw	I1 A	I2 A	n r/min	Pn Kw	I1 A	I2 A			Tm Tn
Item frame	1000r/min synchronous speed 1000r/min
YZR 112M	1.8	5.3	13.4	815	1.5	4.63	12.5	866	2.2	6.6	18.4	725	1.8	5.3	13.4	815	1.5	4.63		12.5		2.5
132M1	2.5	6.5	12.9	892	2.2	6.05	12.6	908	3.0	8	16.2	855	2.5	6.5	12	892	2.2	6.05		12.6		2.86
132M2	4.0	9.7	14.2	900	3.7	9.2	14.5	908	5	12.3	18.2	875	4	9.7	14.2	900	3.7	9.2		14.5		3.51
160M1	6.3	16.4	29.4	921	5.5	15	25.7	930	7.5	18.5	35.4	910	6.3	16.4	29.4	921	5.5	15		15.7		2.56
160M2	8.5	19.6	29.8	930	7.5	18	26.5	940	11	24.6	36.5	900.8	8.5	19.6	29.8	930	7.5	18		16.5		2.78
160L	13	28.6	31.6	942	11	24.5	27.6	957	15	34.7	39	920	13	28.6	31.6	942	11	24.9		27.6		2.47
180L	17	36.7	49.8	955	15	33.8	46.5	962	20	42.6	58.7	946	17	36.7	49.8	955	15	33.8		46.5		3.2
200L	26	56.1	82.4	956	22	49.1	69.9	964	33	62	68	942	26	56.1	82.4	956	22	49.1		69.9		2.88
225M	34	70	85	957	33	62	74.4	962	40	80	101	947	34	70	85	957	30	62		74.4		3.3
250M1	42	80	103	960	37	70.5	91.5	965	50	99	123	950	42	80	103	960	37	70.5		91.5		3.13
250M2	52	97	110	958	45	84.5	95	965	63	121	134	947	52	97	111	958	45	84.5		95		3.48
280S	63	118	142	966	55	101.5	129.8	969	75	144	169.5	960	63	118	142	966	55	101.5		119.8		3.0
280M	85	157	140	966	75	139	124	970	100	185	166	960	85	157	140	966	75	139		124		3.2
750r/min synchronous speed 750r/min
YZR 160L	9	22.4	28.1	694	7.5	19.1	23	705	11	27.5	35.3	679	9	22.4	28.1	694	7.5	19.1		23		2.73
180L	13	29.1	47.8	700	11	27	44	700	15	34	56	690	13	29.1	47.8	700	11	27		44		2.72
200L	18.5	40	67.2	701	15	33.5	53.5	712	22	48	81	690	18.5	40	67.2	701	15	33.5		53.5		2.94
225M	26	55	71.2	708	22	46.9	59.1	715	33	70	92	696	26	55	71.2	708	22	46.9		59.1		2.96
250M1	35	64	80	715	30	63.4	67.7	720	42	75	97.5	710	35	64	80	715	30	63.4		68.8		2.64
250M2	42	86	79	716	37	78	70	720	52	103	98	706	42	86	79	716	37	78.1		70		2.73
280S	52	108	106	712	45	96.5	92	717	63	129	130	704	52	108	106	712	45	96.5		92		3.17
280M	63	126	110	722	55	110.5	92.5	725	75	150	132	715	63	126	110	722	55	110.5		92.5		2.85
315S	85	164.8	177.8	722	75	146.7	156.7	725	100	200	162	715	85	164.8	177.8	722	75	146.7		156.7		2.94
315M	100	190	18.35	715	90	172	160.9	720	125	250	232	717	100	190	183.5	715	90	172		160.9		3.13
600r/min synchronous speed 600r/min
YZR 280S	42	92	177.1	571	37	84.8	153.2	560	55	112	235.2	564	42	92	177.1	571	37	84.8	153.2		2.80
280M	55	127	207	556	45	103.8	165	560	63	146	241	548	55	127	207	556	45	103.8	165		3.16
315S	63	132	161.9	580	55	118.3	138.7	580	75	154	194	574	63	132.5	161.9	580	55	118.3	138.7		3.11
315M	85	179	171	576	75	160	149.3	579	100	210	203	570	85	179	171	576	75	160	149.3		3.45
355M	110	232	246	581	90	192	198	585	132	284	299	576	110	232	246	581	90	192	198		3.33
355L1	132	265	256	576	110	224	207	582	160	324	314	571	132	265	256	578	110	224	207		3.1
355L2	150	292	238	588	132	278	206	588	185	374	296	585	150	292	238	588	132	278	206		3.4
