High Quality Bach Auto EPS Pre-expander Machine with CE

Construction & Decoration

FOB Price:US$ 7,800.00 / Piece(s)

MOQ:1 Piece(s)

Payment Method : L/C T/T Wesstern Union

Keywords:eps pre-expander eps pre-expanding machine eps foam machine

Add to Favorites

Product Category: Construction & Decoration > Trademark:
Product Package: Specifications:
Place of Origin: Port: SHANGHAI

Batch Pre-Expander Machine

summarize:

Batch Pre-expander is to expand EPS raw mateial to required density. Material filling and expanding is done batch by batch, so its called Batch pre-expander.

Batch Preexpander can give more accurate density, easier operation, and its energy saving.

Machine complete with Screw Conveyor, Weighing System, Expansion Chamber, Proportional valve, Fluidized bed Drier



FDS1100FDS1400FDS1660 Batch Preexpander

Item

Unit

FDS1100

FDS1400

FDS1660

Expansion Chamber

Diameter

mm

Φ1100

Φ1400

Φ1660

Usable volume

m3

1.0

1.5

3.5

Steam

Consumption

Kg/cycle

6-8

8-10

11-18

Compressed Air

Consumption

m3/cycle

0.9-1.1

0.5-0.8

0.7-1.1

Throughput

4g/1  230g/h

4g/1  360g/h

10g/1  320g/h

7g/1  350g/h

7g/1  480g/h

15g/1  550g/h

9g/1  450g/h

9g/1  560g/h

20g/1  750g/h

15g/1  750g/h

15g/1  900g/h

30g/1  850g/h

20g/1  820g/h

20g/1  1100g/h

Power

Kw

19

22.5

24.5

Density

Kg/m3

10-40

10-40

10-40

Density Tolerance

%

±3

±3

±3

Overall Dimension

L*W*H

mm

2900*4500*5900

6500*4500*4500

9000*3500*5500

Weight

Kg

3200

4500

4800





More Products

Contact Name: Mrs Sue Wang Contact Email: wa****e@versatile-eps.com
Contact Job Title: Sales Manager Contact Mob: 139***663
Contact Tel: Contact Fax:
Address: Room 1003, Building 4, Wanda Plaza, Huishan District, Wuxi Website:
Wuxi Wealth Engineering Consultancy Co.,Ltd is a company specially dealing with EPS machines, molds and spare parts. Having strong technical team, we help clients to design their new factory and supply whole turn-key project to them, also we help old EPS factories to improve their production by reducing energy consumption and increasing production capacity. Apart from that, we offer the service of designing special machines as per clients request. Our production factory has over twenty years experience in manufacturing EPS machines, professional and qualified. We focus on R&D and care about every detail of machine fabrication. All our machine frames are welded by qualified welders, fully processed by precision CNC machines, through heat treatment, rust treatment, base paint then outer paint. Most accessories used in our machines are imported or famous branded parts with good quality. We do strict checking and testing of every machine before delivery to ensure good quality and good performance. We have over twenty years experienced engineers for start-up and commissioning of equipment, giving systematic training to workers in the client factory so that they can work the plant independently. Advanced technology, good quality and reasonable price is the strength of our equipment; rich technical knowledge, timely response and easy communication is the stength of our team. Till now, our machines have been exported to over fifty countries all over the world, enjoying good reputation in the market. We look forward to your cooperation!
