Botou JCX 760 type metal corrugated profile sheet roll forming machine

Manufacturing & Processing Machinery Industrial Processing Machinery

FOB Price:US$ 9,500.00 / Piece(s)

MOQ:1 Piece(s)

Payment Method : L/C T/T Money Gram Others

Keywords:roll forming machine roll former corrugated tile machine 760 metal roof panel machine Tile Making Machinery wall panel making machine metal roof sheet machine

Add to Favorites

Product Category: Manufacturing & Processing Machinery > Industrial Processing Machinery Trademark: JCX
Product Package: Bare packing, with waterproof cloth and stow-wood. Imported computer control system packed with waterproof cloth and card board. Specifications: 8500*1800*1600mm
Place of Origin: Botou city,Hebei province,China Port: Tianjin

          760 Type Metal Corrugated profile Sheet Roll Forming Machine


Product Description

1. machine pictures









2. Profile drawing



3.  Machine Grahical



4.Parameters:


ItemDescriptionSpecification
1raw materialPPGI/GI
2feeding width1200mm
3feeding thickness0.3-0.7mm
4effective width988mm
5solid shaft materialhugh-grade 45# steel with quenching and tempering and treatment
6shaft diameter70mm
7side wall plate thickness16mm
8roller station18
9machine speed8-15m/min
10drive wayone inch chain
11 motor power5.5 kw
12control typePLC controlled
13encoder brandOmron
14PLC brandDelta/Siemens
15Voltage380V 50 HZ 3 phrases or as client's request



 1. 5 T manual decoiler




2. feeding platform



3. forming part



4. Hydraulic pump station



5. cutting part



6. 3m length receiving platform




Our Services





Company Information



         We have been established in 1995 as a professional manufacturer of ROLL FORMING MALCHINE. We use AUTO CAD design software. With more than 10 years of experience and strict quality control, our products meet International Standard and enjoy great popularity all over the world. Now We are the leading manufacturer of roll forming machine in China.

        We manufacture various kinds of roll forming machines for producing such products as Roof Tile, Wall Panel, Roofing Corrugated Sheet, Floor Deck, C & Z Purling, Highway Guardrail, Sandwich Panel, Container Board, Car Panel, Roll Shutter Door, Downspout, Decorated gusset, Steel Pipe, etc.



FAQ



1. How many times to delivery?



Generally the delivery time is 35 working days.



2. How can you guarantee your machine quality?



I am Elna,sales manager of Botou Golden Integrity Roll Forming Machine Co.,LTD. We are more than 15 years to do and export roll forming machines. And, we have strong engineer team to design your machines' drawings and provide you with comfortable and timely after-sale services. Additionally, we have mature workers to do your roll forming machines. So, buy roll forming machines from our comppany will save money and time.



3. If i don't have profile drawing, how can i buy the machine?



Dear, it's okay. Please provide me with your profile drawing. And answer me some below questions and our engineer will draw for your needed profile drawings.

Question 1: What is your raw material? (GI/PPGI or other special materials?)
Question 2: what is your raw material's thickness? (0.3-0.7mm is a normal range)
question 3:What is your input(feeding)width?


Dear, Please provide me with your Whatsapp number and i can send you our catalog and more details.


4. How to connect you?




Contact Name: Mr. Wang Elena Contact Email: sa****4@jcxsteelrollformer.com
Contact Job Title: Sales Manager Contact Mob: 158***166
Contact Tel: 0086-15831871166 Contact Fax:
Address: NO 5 ROAD , INDUSTRIAL DEVELOPMENT ZONE,BOTOU CITY ,HEBEI PROVINCE, CHINA Website: https://jcxrollformingmachinery.com

Botou Golden Integrity Roll Forming Machine Factory is located in "the town of casting molds", enjoying convenient and highly effective transportation for being close to Tianjin Port, No.104 National Way, No.106 National Way and Jingjiu Railway. Our technical force is abundant. Production equipment is advanced, detection means is complete. We specialize in the professional production of various types of roll forming machines, and the development and production of fully automatic intelligent control roll forming machines of C-shaped steel and dust collector anode plates, and other equipment. On the basis of traditional roll forming machines, we also develop new computer fully automatic roll forming machines, roof and wall panel forming machines, glazed tile forming machines, floor bearing plate forming machines, high-speed barrier devices, double color steel tile molding machines, C and Z steel machines, arch appliances, sandwich composite plate machines, shearing machines, bending machines, and heat insulation sandwich composite machines. Our products have reached the advanced level in the same industry. As beautiful appearance, reasonable structure, and tile-based standards of our products, they are popular among new and old customers. Products are sold to domestic enterprises. Our factory has highly qualified and experienced professionals and highly skilled construction workers to serve you. Our factory can design and produce various kinds of special-shaped cold-formed molding equipment for different needs of the users. You are welcome to contact us for more information.
