Botou JCX 2 waves highway guide rails roll forming machine for sale
Manufacturing & Processing Machinery Industrial Processing Machinery
MOQ:1 Piece(s)
Payment Method : L/C T/T Money Gram Others
Keywords:highway guide rail machine express guide rail machine 2 waves guide rail machine roll forming machine
| Product Category: | Manufacturing & Processing Machinery > Industrial Processing Machinery | Trademark: | JCX |
| Product Package: | Bare packing, with waterproof cloth and stow-wood. Imported computer control system packed with waterproof cloth and card board. | Specifications: | 16000*1300*1400mm |
| Place of Origin: | Botou City, Hebei Province,China | Port: | Tianjin |
standard size W beam 2 waves expressway guiderail roll froming machine
1. Machine picture
2. Finished products' pictures
3. Products' profile drawing
4. Machine Parameters:
| Roller steps | 22 |
| Dimension | 11200*1600*1550mm |
| Weight | 12t |
| Feeding width | 1200mm |
| Forming thickness | 2-4mm |
| Large frame | 450mm H-Beam |
| Diameter of roller | Φ95mm |
| Middle plate | 16-25mm |
| Chain Size | 2 inch |
| Voltage | 380V 50HZ 3 phases or customized |
| Motor power | 15.5kw+15.5kw |
| Pump station power | 5.5kw/ |
| Transducer power | 3.5kw |
| Cutting system | Hydraulic cutting(avoiding noise and smooth cut) |
| Material of cutting | Cr12 |
| Control system | PLC brand :Panasonic |
| Length error : ±2mm | |
| Production capacity | 2-3m/min |
| Warranty | 1 year and we provide technical support for whole life, and overseas service |
| Maintain | Easily :Timely adding oil |
| Payment terms | 30% in advance, the balance before delivery |
| Package | Standard package |
| Delivery | 35 days after receiving the deposit |
5.Machine schematic
Decoiler→Flating→Feeding →Forming→Cut to length→Colletion
6. Machine Parts Introduction
double-head decoiler
High-grade Side wall plates(middle plate) structure
We have been established in 1995 as a professional manufacturer of ROLL FORMING MALCHINE. We use AUTO CAD design software. With more than 10 years of experience and strict quality control, our products meet International Standard and enjoy great popularity all over the world. Now We are the leading manufacturer of roll forming machine in China.
We manufacture various kinds of roll forming machines for producing such products as Roof Tile, Wall Panel, Roofing Corrugated Sheet, Floor Deck, C & Z Purling, Highway Guardrail, Sandwich Panel, Container Board, Car Panel, Roll Shutter Door, Downspout, Decorated gusset, Steel Pipe, etc.
1. How many times to delivery?
Generally the delivery time is 35 working days.
2. How can you guarantee your machine quality?
I am Elna,sales manager of Botou Golden Integrity Roll Forming Machine Co.,LTD. We are more than 15 years to do and export roll forming machines. And, we have strong engineer team to design your machines' drawings and provide you with comfortable and timely after-sale services. Additionally, we have mature workers to do your roll forming machines. So, buy roll forming machines from our comppany will save money and time.
3. If i don't have profile drawing, how can i buy the machine?
Dear, it's okay. Please provide me with your profile drawing. And answer me some below questions and our engineer will draw for your needed profile drawings.
