Brief Introduction

LDA series is Hipower-tek self-developed outdoor LED driver. The two-stage plan helps this series shows extremely high performance. Also, self-researched transformer reaches EIS level Class F (155 degree). Build-in NTC will shut down the driver when case temperature reaches 108 degree and rework when temperature goes down to 80 degree. This driver can work under extreme environment, the working temperature is -40 to 60 degree. Also, it has various available functions such as: 0-10V dimming function, timing control function, programable function. Hipower-tek Hi-set system makes it very convenient to achieve these functions. Nearly 94% efficiency also makes the lifetime of driver be very long which can reach 64000 hours.

Overview

1. Model No.: LDA-120A

2. AC Input Voltage：100-277VAC (90-305VAC)

3. Output Voltage Range: 30-54V

4. Output Power: 120W

5. Power Factor: 0.99 @230VAC

6. Efficiency: 94.5% @230VAC

7. THD: <10% (all range)

8. 0-10V Dimming; Timing control; Programme function available

9. Size: 226*60*44mm

10. Lifetime: >64000 Hours

11. Certification: UL, TUV pending

12. Warranty: 5 years
