50W KLE1016 ATEX Listed LED Hazardous Area Light
Lights & Lighting Explosion-proof light
MOQ:1 Piece(s)
Payment Method : L/C T/T
Keywords:LED Explosion-proof Lights led hazardous location light led light for zone1
| Product Category: | Lights & Lighting > Explosion-proof light | Trademark: | CARY |
| Product Package: | Export paper carton | Specifications: | |
| Place of Origin: | Shenzhen China | Port: | Shenzhen |
50W KLE1016 ATEX Listed LED Hazardous Area Light
1.Product Introduction:
The high quality aluminum alloy housing with 360 °ventilation matrix thermal design achieves maximum heat dissipation and improve life span of light.
This product is widely used in harsh and hazardous places, especially for environment with explosive gas and combustible dust.The rated power covers from 40 to 50W.
2.Specification:
Item | Parameter | |||
Power Rating | 50W | 60W | 70W | 80W |
Voltage Rating | 100-277 VAC | |||
Voltage Frequency | 50-60 Hz | |||
Power Factor | >0.95 | |||
THD | <15% | |||
Light Source | SMD SANAN LED Chip | |||
LED Lifespan | 100000 hours | |||
LED Luminous Efficacy | ≥140 lm/W | |||
LED Luminous Flux | 7000 LX | 8400 LX | 9800 LX | 11200 LX |
Lamp Luminous Efficacy | 85 lm/W | |||
Lamp Luminous Flux | 4250 LX | 5100 LX | 5950 LX | 6800 LX |
Lumen Maintenance | 6000h,>95% | |||
Material | High strength aluminum alloy housing & impact-resistant & frosted tempered glass lens | |||
Lamp Housing Color | Yellow | |||
IP Rating | IP66 | |||
CCT | 4000K/5000K/6000 K | |||
CRI | >70 | |||
Beam Angle | >180o | |||
Driver Brand | SOSEN | |||
Cable Size | Standard: Φ10mm,3×2.5mm2 | |||
Entrance Thread | M25 | |||
EX Mark |
II II 2 D Ex tb IIIC T80℃ Db IP66 | |||
Ambient Environment | Temperature:-40°C-55°C; Humidity:10-90%RH(25°C) | |||
Storage Temperature | -40～60℃ | |||
Dimensions | Φ240*H290 mm | |||
Net Weight | 5.8 KGS | |||
Approved By | ATEX CNEX | |||
Features:
1. High efficiency SANAN LED, whole light efficiency up to 140 lumen/watt.
2. High strength aluminum alloy housing & impact-resistant & anti-glare tempered glass lens,maximum efficacy.
3. Excellent 360 °ventilation matrix thermal design with robust structure.
4. Double seal structure design to ensure no water intake in any environment.
5. SOSEN brand driver, over-temperature protection,high reliability, efficiency > 95%.
6. Energy-efficient technology - up to 80% energy savings over HID fixtures.
7. Surge protection: 8KV.
8. 5 years warranty on all components.
Applications:
Suitable for areas with mounting heights of 2-7m.
Petroleum Industry, Crude Oil Treatment Industry, Metallurgical Industry, Power Generation Industry, Power Transmission Industry, Military Industry etc.
4. Product Details:
PCB board Adjustable bracket Three-chamber
Heat dissipation Stainless Steel Screw Tempered glass
5.Qualification:
6.Deliver,Shipping and Serving:
Delivery Time：
1. Sample orders: 5-7 days
2. Bulk orders: 15-20 days
Shipping Method：
1. Ship by express
2. Ship by air
3. Ship by sea
Our Service：
1. Customized design is available.OEM and ODM are welcomed.
2. One pc sample is acceptable.
3. All of your inquiry will be replied in 10 hours.
4. Protection of your sales area,ideas of design and all your private information.
5. Deliver the goods to our customers all over the world with speed and precision.
6. Rich marketing experiences for more than 6 years.
7. Offer customer with most competitive price and high-end quality led lights.
7. FAQ
Q1: What certification do you have for your LED Explosion Proof Lights?
A: We have CE, ROHS, ATEX, China Explosion proof approval for all of our LED Explosion Proof Lights.
Q2: Can you introduce briefly for your LED Explosion Proof Lights? Are they unique or different from other suppliers'?
A:Cary's LED Explosion Proof Lights are designed and patented independently by Shenzhen Cary technology Co.,Ltd. We ensure quality by using famous brand LED chip, aluminum housing,PC lens and tempered glass. We ensure safety by strict testing and inspection.
Yes. All of LED Explosion Proof Lights are unique, high-quality and safe.
Q3. How long is your LED Explosion Proof Lights guaranteed?
A: We provide 5 years warranty for our LED Explosion Proof Lights.
