Active Power Filter/Harmonic Management and Reactive Power Control Comprehensive Module

Electrical & Power Energy Active & Passive Components

FOB Price:US$ 1,800.00 / Piece(s)

MOQ:1 Piece(s)

Payment Method : L/C T/T

Keywords:APF Active Power Filter harmonic reactive power

Inquire


Add to Favorites

Product Category: Electrical & Power Energy > Active & Passive Components Trademark: TDS
Product Package: Specifications:
Place of Origin: China Port: Shanghai

Main Product Features

(1) The product is horizontal or vertical wall-mounted mounting structure, with push-in bolts in the front and pressing bolts at the bottom to fix, therefore, it is easy to install and fix.

(2) IGBT with large voltage and current margin is adopted in the product, with strong voltage and current shock resistance and stable, so its operation is reliable.

(3) The product can make dynamic track and compensate the active power that change rapidly, characterized by high accuracy and quick responsiveness.

(4) There are various working modes such as harmonic management, reactive power compensation, their combination and others, with good versatility and practicability.

(5) Intelligent temperature monitoring and multiple protection ensure safe and reliable operation of the device.

(6) The product is modular structure, exit of single-unit module will not affect the normal operation of other modules, hence it is with high reliability, moreover, the modules can also be replaced online.

(7) Unique layered heat dissipation channel is designed in the product to realize efficient and fast heat dissipation and ensure long-term stable operation of the product.

Main Product Parameter

(1) Power voltage：～400V±20%。

(2) Capacity：50A、100A、125A、150A……。

(3)  Power consumption：≤3%。

(4) Response time ：≤15ms。

(5) Total harmonic compensation rate：≥90%。

(6) Overall dimension and mounting size : depend on product capacity, the larger the capacity is, the bigger the corresponding size.




Contact Name: Mr Linggang Meng Contact Email: 18****8@163.com
Contact Job Title: Director Contact Mob: 186***588
Contact Tel: 0513-80112058 Contact Fax: 0513-80112020
Address: No. 1188, Yonghe Road Website: www.tds-1300.com
Established in 1993, Jiangsu Modern Electric Technology Co., Ltd is located in Nantong, Jiangsu, and adjacent to Shanghai. The company covers an area of 76500 square meters, with nearly 300 staffs. Modern Electric is manly specialized in research, development, marketing and service in new technology and new products of reactive power control and smart power distribution equipment (smart capacitor, controller, SVG, APF, power capacitor, reactor etc.). The smart low-voltage power capacitor (first developed by our company in China) broke the structural mode of the existing low-voltage reactive compensation equipment, which embodied a significant innovation on low-voltage reactive power control technology. We attach great importance to the technical and product innovation, embellished with 29 Domestic Invention Patents, 30 patents for utility models, 43 Appearance Patents, 2 international patents, etc. Furthrtmore, the company has got 3 State-level scientific research projects, 5 Provincial scientific research projects and 12 Municipal scientific research projects; 1 product is listed as "National Key New Product"; 22 products are awarded as "High-tech Products in Jiangsu Province". The company has passed International Quality System Certification, ISO14001 Environmental Management System Certification and ISO18001 Occupational Health and Safety Management System Certification. Modern Electric Brand (TDS)has been nominated as Jiangsu Provincial Famous Trademark. Products from Modern Electric, based on advanced design philosophy in conformity with development trends, as well as first-class science research equipment and perfect industrialized manufacturing conditions, are superior in performance, and superb in cost-effectiveness, with excellent pre-sale and after-sale service provided, which enabled us to gain extensive recognition and favorable goodwill.
