Structure

C Frame Structure/H-Frame Structure/Floor-mounted Structure

Standards

Design and test by SEFA8,Standards

Customized

Dimension/Color/Structure

Worktop

Epoxy Resin/ Phenolic Resin/Stainless Steel/Ceramic Work Top,

Thickness options: 16 mm/19mm/20mm/25mm,

Color options: Black/ Dark Grey/ Light Grey/ Light Blue / Green/ White

Other required worktop available

Cabinets

Steel cabinet

Slideway: Self-closing,three section slide rail,full extension,noiseless

Handle: C-shape or embedded type,aluminum alloy handle with epoxy coating or stainless steel

Choice of Pull Styles:Flush Full width pulls are standard. Optional pulls in a variety of styles are also

available.

Wrap Around Cabinet Body Construction: The sides, back and outside corner posts of each cabinet are

made from one sheet of 18-gauge cold rolled steel to provide maximum strength and eliminate the need

for an applied finished back.

Powder Coating: applied imported epoxy powder coating provides reliable

chemical and abrasion resistance. Wide variety color available

Steel Finish

Environmentally friendly, electronically applied powder coat finish

Laboratory grade formulation meets all SEFA 8 chemical requirements.

Reagent Shelf

The column is made of 100*50mm supporting bar with 1.5mm thickness with support bracket

Shelves are made of 10mm thickness tempered glass which is height adjustable according to

different requirement

Options for Shelves: 12.7mm Phenolic resin/ 16mm epoxy resin worktop panel.

Socket

Electric sockets, electric circuit breakers and the telephone and computer outlets are located on this

electrical trunking made of PVC and anchored to the shelf vertical supports

Sink/Faucet

Available as required

Accessories

Available as required

Service Column

Available as required
