Underground Welded Ball Valve

Oil & Gas Piping and valves

FOB Price:US$ 80.00 / Piece(s)

MOQ:1 Piece(s)

Payment Method : L/C T/T D/P Western Union

Keywords:Ball Valves

Inquire


Add to Favorites

Product Category: Oil & Gas > Piping and valves Trademark:
Product Package: PLYWOOD CASE Specifications: DN150-DN1500
Place of Origin: Port: SHANGHAI

Product Details



Specification：

2" ~ 40"(DN150~DN1000)

ANSI Ratings 150# ~ 1500# (PN16~PN250)

RF RTJ BW Connections

Main Body Material :

ASTM A105, A182 304, A182 316, A182 304L, A182 316L,A182 F6A,A182,F51,A182 F53,F22 Alloy

Main Ball Material:

ASTM A105, A182 304, A182 316, A182 304L, A182 316L,A182 F6A,A182,F51,A182 F53,F22 Alloy

Main Seats Material:

PTFE/ RTFE(≤120℃) , NYLON (≤80℃), PEEK/PPL  (≤250℃)


Product Details

Underground Fully welded ball valves are especially designed for gas transportation and storage industries. Compared to bolted body, the ex-stem fully welded body design can prevent any potential leakage from connection of body and bonnet. And the forged body has the advantages of consistent grain size and even thickness to ensure reliable and safe sealing performance. Equipped with extension stem, it can work underground. The transition pipe can be welded to the ends of valve during production.


Feature:

Body and bonnet welded integrally design

Extension stem

Double Block & Bleed Design

Optional under-ground & extended stem design

Fire-safe Certified API 607

Blowout-proof stem

Antic-static device

Low Fugitive Emission Packing

Cavity pressure self-relief

Optional double piston design

ISO 5211 Mounting Pad


Contact Name: Mr stone Xu Contact Email: in****o@cz-valve.com
Contact Job Title: Marketing Manager Contact Mob: 130***523
Contact Tel: Contact Fax:
Address: Website: www.cz-valve.com
CHANGZHOU CENYON VALVE TECHNOLOGY CO.,LTD.is a ball valve industrial leader, founded in 2004, located in ChangZhou city, JiangSu Province. Taking a land of 50,000.00㎡in a place of beautiful environment and convenient transportation, the company is integrated with research, development, manufacturing, testing, sales and service.



It has more than 170 employees, among of which, more than 50 technical staffs, 4 engineers and 1 senior engineer. They forms a experienced and excellent technical group, aiming to develop and promote valve quality.



The company not only has reliable technical force, but also has the advanced equipments and facilities. It owns more than 100 sets of all kinds of high-precision processing equipments, including CNC machining centers (CNC milling/drilling/boring/ grinding lathes, large CNC vertical/horizontal lathe), plasma arc welding, automatic gas shielded arc welding, drencher environmental protection and automatic spray paint lines, etc.



And the company is well provided with physical and chemical laboratory. The existing detection equipments include spectrometer, hardness tester, universal testing machine, tensile impact testing machine, YFT automatic hydraulic valve tester, acoustomotive thickness tester, low temperature test chamber, low temperature impact testing machine, etc. All the perfect facilities can meet customers’ maximum production and inspection demands.



By years of efforts, the company has been certified to the ISO9001 quality system, API-6D, API607 fire test, CE, ISO14001 environmental management system certification, GB/T28001occupation health and safety management system certification, China pressure piping components manufacturing license(TS) certification, etc.



We specializes in producing various kinds of ball valve and ball valve parts. Valves can be designed and produced in accordance with different standards: ISO, GB, API, BS, DIN,NF, JIS, etc.,

Product diameter: 1/2 inch-48 inch;

Nominal Pressure: 150LB-2500L;

Operation Temperature:-196-650℃;

Connection: flanged, threaded, welding, etc.,



Material:A105(WCB),LF1(LCB,LCC),LF2(LC1),LF3(LC2),F11(WC6),F22(WC9),F51,F304(CF8),F316(CF8M), F304L(CF3)F316L(CF3M);

We uphold the "customer success, innovation and integrity, shared values" as business philosophy.  We have been recognized by the industry with sincerity, power and product quality.

Welcome friends from all over the world to visit us.
