GYTA333 Outdoor Fiber Optical Cable Steel Wire Armored Optical Cable

Electronics and Communications communication device

FOB Price:US$ 1.00 / Meter(s)

MOQ:2000 Meter(s)

Payment Method : L/C T/T D/P Western Union Paypal Money Gram

Keywords:Cable Fiber Optic Cable Duct Cable Communication Cable Network Cable Fiber Optic FTTH Optical Cable Optical Fiber Cable Fiber Cable

Add to Favorites

Product Category: Electronics and Communications > communication device Trademark: Hongan or customized
Product Package: Wooden Reel or Customized Specifications: 2km per roll or customized
Place of Origin: China Port: Qingdao
Product Description

Hongan group 2cores single mode submarine fiber optic cable GYTA333

GYTA333 fiber optic cable is the type of fiber optic cable used in shallow-water as well as climbing lay.  In other words, GYTA333 fiber optic cable is referred as an underwater cable since is used under water. In most cases, the GYTA333 fiber optic cable is laid in the water drainage and it has fantastic feature that enables it to perform effectively under water environments.  Additionally, GYTA333 fiber optic cable has a humidity resistance as well as excellent mechanical property that prevents it from breaking. Also, it is rodent-proof as well as termite-proof and that makes it adapt well to watery environment.

Fiber count
Structure
Fibers per tube
Loose tube diameter(mm)
CSM diameter/pad diameter(mm)
Thickness of Inner jacket(mm)
Thickness of outer jacket(mm)
Cable diameter(mm)
Cable Weight(kg/km)
4
1+5
4
1.7±0.1
1.4/1.4
0.9±0.1
1.8±0.1
14.8±0.5
464
6
1+5
6
1.7±0.1
1.4/1.4
0.9±0.1
1.8±0.1
14.8±0.5
464
8
1+5
4
1.7±0.1
1.4/1.4
0.9±0.1
1.8±0.1
14.8±0.5
465
12
1+5
6
1.7±0.1
1.4/1.4
0.9±0.1
1.8±0.1
14.8±0.5
465
18
1+5
6
1.7±0.1
1.4/1.4
0.9±0.1
1.8±0.1
14.8±0.5
465
24
1+5
6
1.7±0.1
1.4/1.4
0.9±0.1
1.8±0.1
14.8±0.5
466
30
1+5
6
1.7±0.1
1.4/1.4
0.9±0.1
1.8±0.1
14.8±0.5
466
36
1+6
6
1.7±0.1
1.8/1.8
0.9±0.1
1.8±0.1
15.2±0.5
491
48
1+5
12
2.0±0.1
1.4/1.4
0.9±0.1
1.8±0.1
15.5±0.5
498
60
1+5
12
2.0±0.1
1.4/1.4
0.9±0.1
1.8±0.1
15.5±0.5
499
72
1+6
12
2.0±0.1
2.0/2.0
0.9±0.1
1.8±0.1
16.2±0.5
556
84
1+7
12
2.0±0.1
1.8/2.9
0.9±0.1
1.8±0.1
17.1±0.5
601
96
1+8
12
2.0±0.1
1.8/3.5
0.9±0.1
1.8±0.1
18.2±0.5
696
108
1+9
12
2.0±0.1
1.8/4.2
0.9±0.1
1.8±0.1
18.9±0.5
744
120
1+10
12
2.0±0.1
1.8/4.9
0.9±0.1
1.8±0.1
20.4±0.5
926
132
1+11
12
2.0±0.1
1.8/5.5
0.9±0.1
1.8±0.1
21.0±0.5
959
144
1+12
12
2.0±0.1
1.8/6.3
0.9±0.1
1.8±0.1
21.8±0.5
1024









Item

Parameters

Loose tube
Material
PBT


Color
All colors display

Filler
Material
PE


Color
Black

CSM
Material
Phosphating steel wire

Armoured
Material
Plastic coated aluminum strip

Inner jacket
Material
MDPE


Color
Black

Steel wire armoured
Material
Galvanized steel wire

Outer jacket
Material
MDPE


Color
Black

Min. bending radius
Static
15times cable diameter


Dynamic
30times cable diameter

Repeating bending
Load:250N;number of cycles:30 No obvious addition attenuation, no fiber break and no cable damage.

Tensile performance
Short term
20000N

Crush
Short term
5000N/100mm

Torsion
Load:250N; number of cycles:10; twist angle:±180° No obvious addition attenuation, no fiber break and no cable damage.

Impact
Impact energy:1kg×1m; radius of hammer head:12.5mm; number of impact: 5 ,no fiber break and no cable damage.


Packing & Delivery
Certifications
Our Company
FAQ

1. Are you the real factory?

Yes,our factory is located in Shandong Province, near to Qingdao Port,having more than 30- years munufature experience. Welcome to visit.
2. What is your fiber brand?
Most fiber is from Weixin, a fiber brand owned by Hongan ourselves. But we also purchase fiber from Corning, YOFC and other brands.
3.What is your main products?
Our main products are outdoor and indoor fiber optic cable, FTTx cable, network cable and telephone cable.
4.What is your payment term?
30% in advance, 70% before delivery.
