1. 概述 General Introduction

SCST-241型甲烷化催化剂用于将天然气、焦炉气、煤制气等合成气中CO、CO₂和H₂转化为CH₄的过程，主要用于深度净化，使气体中CO+CO₂≤10ppm。经改性后，也适用于以煤、焦炉气为原料合成CNG、LNG等装置，转化率达99.9999%以上。

Methanation catalyst SCST-241 is mainly suitable for synthesis ammonia or hydrogen producing plant to convert the low concentration of carbon monoxide and carbon dioxide in the hydrogen-enriched feed gas to methane and water. The conversion rate is above 99.9999%.

主要反应如下：the main reactions are as following:

CO+3H₂ = CH₄+H₂O+206.2 kJ/mol

CO₂+4H₂ = CH₄+2H₂O+165 kJ/mol

2. 物化性能 Physical and Chemical Properties

可根据用户需要提供其他尺寸的催化剂。

Catalysts of other sizes can be supplied according to the needs of users.

3. 操作工艺条件Operation Conditions

4. 催化剂特性Product Advantages

1) 还原时间短，22小时可以串气，节约还原时间，降低能耗；

Shorter reduction time and saving energy and the material gas can enter after 22 hours ;

2) 耐高压、高空速，在32Mpa压力下运行空速可以到达15000^-1；

Resistance to high pressure, high space velocity: The space velocity can reach 15000h^-1 at 32MPa;

3) 新型助剂添加，转化率高、低温活性好，出口一般低于5ppm；

With the new auxiliaries addition, it has a high conversion and high activity at low temperature. the outlet usualy is less than 5ppm;

4) 本体不含物理水、体积收缩率低，还原后强度下降率低；

No physical water, lower volume shrinkage and lower strength reduction rate after reduction.
