SCROLL SLT-I MEDI series

The SLT-I MEDI was developed especially for the medical application. All components used are proven and tested over many years and matched with each other.

The mobile SCROLL compressor with electronic control RENNERtronic and integrated Medipac delivers clean, dry and oil-free compressed air in breathing air quality in compliance with all relevant international standards, such as Pharmacopée européenne and DIN EN 12021.

The SL-I series are high efficient compressor units due to a rigid and a contactless rotating spiral compression element, combined with the use of high-quality materials, this guarantees safe and long-lasting operation and ensures a low-pulsation compressed air flow.

The belt driven compressors are ideally suited for both short-term and continuous operation. They impress with their compact design, smooth running and high reliability.

Optional features for all single unit compressors: air receiver, electronic control RENNERtronic Plus and pre-filter frame.

Performance range

Motor power: 2,2 + 5,5 kW
Free air delivery: 195 + 520 l/min
Operating pressure: max. 10 bar

Advantages

• High-quality, clean, dry and oil-free compressed air in breathing air due to 100% oil-free compression process and integrated Medipac with adsorption dryer, CO, CO2, NOx and SO2 separation

• Separate sterile filter

• Pre-, afterfilter and automatic condensate drain

• Mobile due to four swivel heavy duty castors

• Stable and robust due to manoeuvring handles and bumpers

• Easy to maintain and control thanks to removable side doors and easily accessible, internal components

• User-friendly due to functional and clearly arranged instrumentation panel

• Rotation direction control of the compressor

• Electric supply: 400 V / 3 phases, 2.2 kW also with 230 V / single phase

• Quick installation – ready-to-connect delivery incl. electric cable and ball valve with air-side connection
