Laboratory Ducted Fume Hood
Furniture & Interiors Design Commercial Furniture
MOQ:1 Piece(s)
Payment Method : L/C T/T
Keywords:Laboratory Ducted Fume Hood Laboratory Fume Cupboard All Steel Fume Hood Chemical Fume Hood PP Fume Hood
| Product Category: | Furniture & Interiors Design > Commercial Furniture | Trademark: | UFH |
| Product Package: | All goods are to be packed in seaworthy export standard packages according to international standards. | Specifications: | 1200/1500/1800(W)*1205（D）*2400（H）(mm) |
| Place of Origin: | China | Port: | Shanghai |
Product Characteristics:
1. Full-assembly structure hence easy installation;
2. Corrosion resistance, and high-temperature resistance ;
3. Unique down return air flow deflector, exhaust air timely and effective without residue ;
4. Exclusive and proprietary uniform flow design maket the uniform flow rate without any residue of exhaust air ;
5. Visual-range of internal of fume hood will not form condensate due to temperature difference, hence no drip phenomenon ;
6. Internal air flow direction won't be affected by the exhaust air volume, will not cause air flow disorder ;
7. Low energy consumption, high-class of automation and intelligence, simple operation ;
8. Fume hood has the air compensation channels, adopts external air compensation within same fume hood body, energy saving and comfort ;
9. Drainage is not limited by the height of the drain port, due to it through the chemical sewage pump to enhance discharge.
Product function：
1. Extract the exhaust gas;
2. Fresh air compensation;
3. Inorganic waste gas purification ;
4. Sewage treatment (acid-base neutralization);
5. In auto mode, one key for start-stop the electromechanical device through the built-in program ;
6. In manual mode, Can independently start and stop the electromechanical device;
7. Visualization of operation state of each electromechanical device ;
8. Automatic fault alarm;
9. Purification system resistance monitoring: Automatic alarm when exceeding the set value;
10. Purification system temperature monitoring: Automatic alarm when exceeding the set value;
11. On-line monitoring of PH values of spray media;
12. Automatic monitoring of liquid level of acid, alkaline solution and spray media;
13. Automatic dosing system of acid and alkali solutions (via dosing pumps);
14. Automatic discharge of sewage through built-in procedures (via sewage pumps) and cleaning of spray systems (via spray pumps);
15. Automatic replenishment of tap water (via solenoid valve);
16. Provide safe power: includes lost-phase protection and phase-sequence protection; Emergency powered off; Electric leakage protection; Power master control;
17. Provide safe light sources: includes brightness-adjustable white light and two-color LED light without ultraviolet yellow light;
18. Lack-water protection for sewage pump and spray pump;
19. Thermal overload protection for electromechanical device;
20. Over-height alarm for sliding doors;
21. Use an electric control valve to control the exhaust volume;
22. Other functions: water supply terminals and gas supply terminals can be installed according to the needs of customers,etc.
Chengdu Ample Import and Export Co., Ltd. is a professional solution-oriented supplier located in Chengdu. With more than decades' experience in laboratory industry, Ample is engaged in developing, manufacturing and exporting laboratory equipment and furniture, ergonomic chairs, etc. Meanwhile, we have built a good cooperation with Chinese high-quality manufacturers. Aim to focus on being one of the most professional centralized procurement and supply service provider for customers all over the world. We have completed the upgrading and transformation of the laboratories of hundreds of enterprises, scientific research institutions, inspection, and testing institutions, and thoroughly solved the difficulties and pain points that have existed in the laboratories for a long time. Our products have been widely used in the food and pharmaceutical industry, metallurgy, mining, agricultural testing institutions, food, and pharmaceutical testing institutions, customs import & export inspection and Quarantine Bureau, feed industry, cosmetics industry, petrochemical industry, hospital, etc., and received unanimous praise. To benefit more enterprises, we are committed to expanding the market of our products, helping more enterprises and institutions to improve their laboratory environment, providing more high-quality security for laboratory personnel, and making greater contributions to the protection of the environment! Our company tenet is Top in Quality, Best in Service. Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs. Trust us, we can provide you professional suggestion and service. Let's create more value for you and be the power of your success!
