9YQ-2200A Hay Straw Square Baler
Agricultural Agricultural Machinery
MOQ:1 Set(s)
Payment Method : T/T D/P Western Union Paypal
Keywords:Agricultural Balers Baler straw baler hay baler
| Product Category: | Agricultural > Agricultural Machinery | Trademark: | DEWO |
| Product Package: | Specifications: | ||
| Place of Origin: | Heilongjiang of China | Port: | Dalian |
Features:
1. All the knotters and key bearings are imported, the failure rate is low, the maintenance cost is reduced, and the bale rate is higher than 98% to meet international standards.
2. High-definition camera monitoring system allows the driver to clearly understand the operation of the equipment and make adjustments in time.
3. Large-range, high-bright searchlights provide lighting for night operations, giving the operator a good line of sight.
4. The high-speed pick-up shaft is combined with the hard alloy claws optimized for shape design. It has large wind force at high-speed rotation, good suction power to the straw, clean pick-up, low soil content, repetitive rubbing of straw, and good palatability. , is the first choice for feed.
5. The belt pulley adopts the European standard taper sleeve connection, which is safe and reliable to use, and easy to adjust and disassemble.
6. Extended molding room, so that the bale shape standard, which facilitates loading and unloading and stacking.
7. Use 10.0/75-15.3 large-diameter widening tires to accommodate more terrain and have greater passability.
Model | 9YQ-2200 | 9YQ-2200A |
Overal size（mm） | 6130×2637×1730 | 6500×2640×1730 |
Motive power （kW/hp） | ≥60/80 | ≥60/80 |
Pick up width （mm） | 2200 | 2200 |
Bale size（mm） | 360×460×(300-1300) | 360×460×(300-1300) |
Productivity （t/h） | 3～6 | 3～5 |
Feeding in speed （kg/times） | ≥2.6 | ≥2.0 |
Availability （%） | ≥98 | ≥98 |
Baling piston speed （travel/min） | 100 | 100 |
Crushing cutter shaft number | 1 | 2 |
Knotter type | D | D |
