4JHM Straw crushing machine
Agricultural Agricultural Machinery
MOQ:1 Set(s)
Payment Method : T/T D/P Western Union Paypal
Keywords:Straw crushing machine
| Product Category: | Agricultural > Agricultural Machinery | Trademark: | DEWO |
| Product Package: | Specifications: | ||
| Place of Origin: | Heilongjiang | Port: | Dalian |
4JHM series hanging potato special killing machine is based on China's potato agronomic requirements, developed on the basis of absorbing foreign advanced equipment and advanced technology. It is a special potato imitating ridiculous killing equipment suitable for China's national conditions. It is suitable for the 80cm and 90cm potato planting rows.
Features:
1. Adopt three-point full-suspension structure, use wheeled tractor with hydraulic lifting mechanism and rear power output as power machinery to work. The high-speed rotation of the drum drives the high-speed rotation of the killing knife, and the rapid cutting of stems and leaves by the sledgehammer completes the operation.
2. Four types of slaughter burrs are distributed and arranged in strict accordance with the different row spacing of potato ridges to achieve ridge-like profiling and can complete the killing and killing of all potato pods on ridges and ridges, realizing a complete annihilation. seedling.
3. The protective device under the front of the implement can safely and effectively prevent the damage of soil, stones and other hard objects to the locomotive and human body.
4. The machine has many advantages such as economical and practical, simple and convenient operation, large power adaptability range, high operating efficiency, and strong regional adaptability.
Type | 4JHM-360 | 4JHM-320 |
Assembly form | Three-point suspension type | Three-point suspension type |
Motor power （kW/hp） | ≥66.2/90 | ≥66.2/90 |
Working width （mm） | 3600 | 3200 |
Stubble height （mm） | ≤80 | ≤80 |
Weeds removing rate （%） | ≥85 | ≥85 |
Chopped length （mm） | ≤120 | ≤120 |
Chooper structure type | Blade type | Blade type |
Working rows | 4 | 4 |
Ridge space （mm） | 900 | 800 |
Ridge height （mm） | 160～250 | 160～250 |
