Summary:

The mill is intended for manufacturing of round pipe of Φ25mm-Φ76mm with thickness of 1.2mm–4.0mm from cold-rolled and hot-rolled coil strip by means of unclosed tubular blank with its subsequent welding into tube, edge heating by means of solid state high-frequency welder, longitudinal seam welding in rolls of tube welding machine, cooling, further sizing or shaping and on-stream cutting of endless tube in measured lengths.

Finished product will be of round pipe, square and rectangle pipe.

The technical flow of the production line:

{SteelTape}→→ Double-head un-coiler →→Strip-head Cutter and welder→→Spiral accumulator→→Forming section (Flattening unit +Main driving unit +Forming unit +Guide unit +High frequency induction welding unit +squeeze roller) + De-burr frame →→Cooling unit →→ Sizing unit and straightener →→Cold saw under computer-control →→ Run-out table→→ Semi-auto Packing machine

Shijiazhuang Rokan Machinery Technology Co.,Ltd is the professional manufacturer of the welded steel pipe production line, cold roll forming line, slitting line, cut-to-length line and the related auxiliary equipment. Teneng company is the modern enterprise which capable of research and development, production and sales. Teneng is a council member of China Roll Forming Association,a president member of Hebei Steel Tube Trade Association.Teneng machines are the most effective tube manufacturing equipment available in the world.In China, the well-known users are Hebei Jingye Group, SANY Group, China Shipbuilding Industry Corporation, Chongqing Changzheng Heavy Industry Co., Ltd etc.
