Compressor

Oil & Gas Oil and Gas Equipment

FOB Price:US$ Customizable price / Set(s)

MOQ:1 Set(s)

Payment Method : T/T

Keywords:Compressor

Add to Favorites

Product Category: Oil & Gas > Oil and Gas Equipment Trademark:
Product Package: Specifications:
Place of Origin: Port: qingdao
Z series
Power range85~630kW
Gas displacement0.1~100×104Nm3/d
Maximum exhaust pressure35MpaG
Application areaIt can be used for gas collecting, oil and gas treatment and processing, gas lifting and light hydrocarbon recovery.
working mediumNatural gas, coal bed gas, shale gas, oil field associated gas, flash vapor, air, nitrogen, carbon dioxide, hydrogen, nitrogen hydrogen and so on.


R series
Power range10~7500kW
Gas displacement0.1~500×104Nm3/d
Maximum exhaust pressure 52MPaG
Application areaIt can be used for gas collecting, gas production and gas injection (gas storage), oil and gas treatment and processing, gas lifting, light hydrocarbon recovery, natural gas liquefaction, refining, gas drilling and pipeline pressure testing.
working mediumNatural gas, coal bed gas, shale gas, oil field associated gas, flash vapor, air, nitrogen, carbon dioxide, hydrogen, nitrogen hydrogen and so on.


D series
Power range10~7500kW
Gas displacement0.1~500×104Nm3/d
Maximum exhaust pressure 52MPaG
Application areaIt can be used for gas collecting, gas production and gas injection (gas storage), oil and gas treatment and processing, gas lifting, light hydrocarbon recovery, natural gas liquefaction, refining, gas drilling and pipeline pressure testing.
working mediumNatural gas, coal bed gas, shale gas, oil field associated gas, flash vapor, air, nitrogen, carbon dioxide, hydrogen, nitrogen hydrogen and so on.


C series
Power range10~7500kW
Gas displacement0.1~500×104Nm3/d
Maximum exhaust pressure 52MPaG
Application areaIt can be used for gas collecting, gas production and gas injection (gas storage), oil and gas treatment and processing, gas lifting, light hydrocarbon recovery, natural gas liquefaction, refining, gas drilling and pipeline pressure testing.


Q series
Gas inlet pressure1.0~2.4MPaG
Gas OUTlet pressure17~50MPa
Gas displacement 25~100Nm3/min
Work Mode24 continous working mode
Application areaThe compressor set is suitable for drilling operations of pure air, air atomization, air foam liquid, air inflation and nitrogen in 6 '~ 171/2' wellbore. It is the only air pressurization compressor used for underbalanced drilling in China.


Integrated oxygen reducing and pressurizing device
Gas inlet pressure1.0~2.4MPaG
Gas displacement25~100Nm3/min
Maximum exhaust pressure17~50MPa
working mediumAir, nitrogen, oxygen - reducing air, etc.
Application areaIt can be used in gas injection, gas drilling, pipeline pressure testing and other fields.


Contact Name: Miss Xuan Zhang Contact Email: 28****5@qq.com
Contact Job Title: Sales And Marketing Contact Mob: 150***396
Contact Tel: Contact Fax:
Address: No.11966 West Jingshi Rd., Jinan Website: www.jichai.com

CNPC Jichai power company limited is located in the economic development zone of the Jinan city, Shandong province. The company was founded in 1920 and is the only internal combustion engine manufacturing enterprise belonging to CNPC . In 1965, Jichai successfully developed 12V190 high power diesel engine, which filled in gaps of national oil drilling power. In 1988, Jichai produced the first high power gas engine of China.Over 50 years, 190 series diesel engine has occupied more than 90% market share of oil-drilling power, and made a great contribution to national oil industry.



The main business of Jichai is R&D and manufacture of medium and high-power internal combustion engines, compressor and relative power equipment. At domestic advanced level in the same industry. Jichai products are widely used in oil drilling, marine power, power stations, locomotives and military products, etc. At present, Jichai has formed with multi-bore diameter engine products (140mm, 175mm, 190mm, 260mm and 270mm) with medium and high speed to cover the power range of 200~9000kW to meet the customers power requirements in different fields.



Jichai product are distributed all over country oil and gas field and 32 provinces and regions, have been exported to over 60 countries and forming a diversified market structure. Jichai has a national-level enterprise technology center, 55 national and industry standard marking rights, and 98 national patents, Jichai is the top 500 machinery manufacturing enterprises in China, and has won the National Quality Management Award, National Customer Satisfaction Enterprise, passed the ISO9001 quality management system, HSE management system and been regarded as 3A class enterprise by CAQ. Jichai products also passed the EU safety certification, and the certification of BV, RS etc.



In 2020, jichai will celebrate its centenary. New era, new journey, new leap. Jichai will adhere to innovation driven, promote high-quality development, and strive to build a world-class power equipment R & D and manufacturing service enterprise!
