Tractors Mini 4x4 50HP Compact Tractor With Loader And Backhoe
Agricultural Agricultural Machinery
MOQ:1 Piece(s)
Payment Method : L/C T/T Western Union Paypal
Keywords:tractors Agricultural Tractors mini tractor farm tractor small agricultural tractor mini farm tractor tractors for agriculture 4wd 4wd compact tractor 4x4 mini tractor 70hp tractor
| Product Category: | Agricultural > Agricultural Machinery | Trademark: | Tavol |
| Product Package: | plywood box | Specifications: | TL704 |
| Place of Origin: | Shandong, China | Port: | Qingdao |
>>>>>>70HP Tractor Parameter<<<<<<
70HP agriculture equipment traktor feature:
1.70HP, 4WD
2.Dual-stage clutch
3.Hydraulic steering
4.Gearshift 8F+8R
5.Tire size: 6.5-16/11.2-14
6.Tractor implements are available
7.Comfortable cabin are optional
Tavol 70hp Tactor Main Parameters | ||
Model | TL704 | |
Machine parameters | Type | 4×4 |
Rated Traction( KN) | 16.2 | |
PTO Max Power (KW) | 43.8 | |
Dimensions(mm) | 3560×1650×2350 | |
Wheelbase(mm) | 1965 | |
Track(mm) | Front wheel(mm) | 1150 |
Rear wheel(mm) | 1200-1360 | |
Ground clearance(mm) | Minimum ground clearance(mm) | 330 |
Minimum turning cricle radius | Use unilateral braking | 2.85±0.20 |
Not unilateral braking | 3.15±0.30 | |
Minimum use quality | 1660 | |
Gearbox | 8F+8R Shuttle Shift | |
Steering System | Hydraulic steering gear | |
Drive Train | Clutch | Dual stage clutch |
Working equipment | Maximum lifting force at 610mm(KN) | 10.85 |
Suspension mechanism | Three-piont suspension type 1 or 2 | |
PTO shaft | PTO Spedd(r/min) | 540/760(option: 540/1000) |
Tire | Front wheel specifications | 6.5-16/7.5-16/7.5-20 |
Rear wheel specifications | 11.2-24/12.4-24/12.4-28 | |
Engine | Type | Inline, 4 stroke, Water cooled |
Cylinder | 4 | |
Optional | Cabin | AC/Heater |
Roll bar | ||
Perfusion volume | Radiater(L) | 15 |
Fuel tank(L) | 50 | |
Engine oil pan(L) | 5 | |
Driveline oil (L) | 20 | |
Lifter(L) | 9.5 | |
This parameter table is for reference only, everything is based on actual products | ||
>>>>>>Tractor Implemet<<<<<<
Tavol tractor is designed with multitandem valve,you can have different kinds of attachment/implement to achieve fine work.
>>>>>>About Tavol<<<<<<
Shandong Tavol Group Co., Ltd is a High-tech Groups Companies, Which Engage in High-end Agricultural Equipment Manufacturing, Construction Machinery and High-precision Monitoring Sensors.
About Tavol Tractor:
1-Tractors export experience from 2007,
2-Serves more than 150 countries such as Canada, Germany, Brazil, UK, Bangladesh, Philippines, Sri Lanka,Vietnam , Maldives, Cambodia, Oman, Saudi Arabia, Kenya, Guinea, Georgia, Indonesia, South America,etc.
3-After-sale agents in more than 20 countries,
4-Foreign exhibition more than 10 countries,
5-China Agricultural machinery exhibition 5 years.
Products range: 15hp-200hp Farm Tractors and Other Farm Machines. Adopt Strict Production
Technology and Inspection Standards, Select the Best Quality Brand Tractor Parts. To ensure a 100% Quality Standard, We will Independent Development and Production the Core Tractor Parts, Continue to Increase Investment in New Models and Technologies.
We are sure we will be your best choice .
>>>>>>FAQ<<<<<<
1) Manufacturer or Trading Company
We are a leading tractor manufacturer
(2) Delivery Time
Usually 25 days. In peak season,30-40 days
(3)Payment Terms
T/T, L/C, Western Union, Paypal.
(4)Tractor Options
Can be equipped with ROPS, Canopy, Cabin, AC Cabin, Air Brakes, Hydraulic Valve Out, Paddy Tire or as per your requirements.
(5)Tractor Logo
We have our own logo. And we also can put your logo for free.
(6)Tractor Implements
Rotary tiller, disc plow, furrow plow, cultivator, front end Loader, backhoe, Mower, Trailer, Snow Blower or as per your requirements.
