This series of machine tools adopts a gantry fixed beam structure and uses the periphery or end of the grinding wheel to grind the surface of the workpiece. It is suitable for grinding various guide rails and the plane of wide and large parts in machinery manufacturing, automobiles, molds and other industries.

Features:

●Adopt stepped beam and large column gantry frame structure to make the grinding head load evenly distributed and ensure the rigidity during heavy grinding.

●The bed and worktable are made of high-precision wear-resistant cast iron, with optimized structural design, excellent bending and torsion resistance, and stable accuracy.

●The reciprocating motion of the worktable adopts a push-pull cylinder, a large-flow double pump, and an independent hydraulic station drive, which eliminates the influence of the temperature rise of hydraulic oil and lubricating oil on the accuracy of the machine tool; the guide rail is pasted with a PTFE soft belt, which is wear-resistant Good performance and low noise.

●Vertical feed and lateral feed are driven by servo motor and precision ball screw driven by reducer, and electronic handwheel can be used for tool setting and micro feed.

●The grinding head adopts imported precision rolling bearing spindle, and the horizontal grinding head is also equipped with a dynamic and static pressure spindle; it is equipped with a hydraulic balance cylinder to reduce the load of the vertical screw.

●The longitudinal guide rail adopts automatic continuous lubrication, and the vertical and horizontal guide rails and the lead screw pair adopt automatic centralized lubrication, which effectively prevents strains due to oil loss.

●Cooling box equipped with magnetic separation filter to ensure the circulating use of coolant.

●The program control system is equipped with an Omron programmable controller as standard, and the grinding process parameters can be set or changed on the display screen. The operation is simple and convenient, and the price is high; Ke, Guangshu and other systems, or increase the form grinding function.
