mini tractors /Mini tractor with single cylinder diesel engine
Agricultural Agricultural Machinery
MOQ:16 Set(s)
Payment Method : L/C T/T D/P
Keywords:mini tractors belt tractors small tractors agricultural tractors
| Product Category: | Agricultural > Agricultural Machinery | Trademark: | SHIFENG |
| Product Package: | packed in iron frame | Specifications: | SF240/SF250/SF300 |
| Place of Origin: | LIAOCHENG | Port: | QINGDAO |
Shifeng mini belt transmission tractors with 15-32 HP ;
equiped with single cylinder diesel engine, Janpanese technology & BOSH injection system;
Front Radiator with dual cooling system;
Gearbox with ten shifts with rear PTO for farming works;
Bigger tire with high ground clearance for rough road transportation;
| ⒈ Overall Data of Tractor | |||||||
| Model | SF180 | SF200 | |||||
| Type | 4X2 | 4X2 | |||||
| Model of Engine | SF1110 | SF1115 | |||||
| Rated Traction(N) | 2800 | 2800 | |||||
| Overall Dimensions （mm） | Length | 2650 | 2650 | ||||
| Main Dimensions of Tractor | Width | 1400 | 1400 | ||||
| Height | 1280 | 1280 | |||||
| Wheel Base（mm） | 1400/1470 | 1400/1470 | |||||
| Tread（mm） | Front Tread | 1140 | 1140 | ||||
| Rear Tread | 1200 | 1200 | |||||
| Min Ground Clearance | 280 | 280 | |||||
| Min Turning Radius（mm） | 2900 | 2900 | |||||
| Structure Mass | 835 | 895 | |||||
| Mass of Tractors KGS | Min-Usage Mass | 1080 | 1100 | ||||
| Bob Weight | Front Bob-weight | 20/30 | 20/30 | ||||
| Rear Bob-weight | 60 | 60 | |||||
| (Steel Band) | |||||||
| Rear Bob-weight | 35 | 35 | |||||
| (Cast Iron Band) | |||||||
| Distribution of Mass | Front Wheel | 410 | 410 | ||||
| Rear Wheel | 670 | 670 | |||||
| Model of Chassis | Half Floating | Full Floating | |||||
| Model of Front Axle | Non adjustable type | Non adjustable type | |||||
| Theoretical Speed (Km/h) | I gear | 3.03 | 3.03 | ||||
| IIgear | 4.98 | 4.98 | |||||
| III gear | 7.12 | 7.12 | |||||
| IV gear | 8.5 | 8.5 | |||||
| V gear | 11.12 | 11.12 | |||||
| VI gear | 13.97 | 13.97 | |||||
| VII gear | 19.97 | 19.97 | |||||
| VIII gear | 31.19 | 31.19 | |||||
| Rev.I gear | 4.01 | 4.01 | |||||
| Rev. II gear | 11.25 | 11.25 | |||||
| Hydraulic systerm | type | half- independent | half- independent | ||||
| pump posision | side | side | |||||
| Pressure for safety vavle (Mpa) | 15±0.5 | 15±0.5 | |||||
| Hydarulic cylinder Bore x Strode (mm) | 63×77 | 63×77 | |||||
| displacement (l/min) | 7.5 | 7.5 | |||||
| lifeter travel (mm) | 420 | 420 | |||||
| Max lifting capacity (KN @610MM) | 4 | 4 | |||||
| Lifting time (s) under the rated engine speed | 3 | 3 | |||||
| working device | type | rear 3-point links,cat O | rear 3-point links,cat O | ||||
| deepth for the implemet control | floating | floating | |||||
| Diameter track pin | φ28 | φ28 | |||||
| Groudclearance for the drawing bar | 480 | 480 | |||||
| type | side, non-independent | side, non-independent | |||||
| speed (r/min) | 720 (540) | 720 (540) | |||||
| PTO shaft | model I35 | model I35 | |||||
| Remarks: The usage mass includes the mass of driver, bob-weight, fuel and cooling water, etc. | |||||||
| ⒉ Data of Engine | |||||||
| Model | ZS1110 | ZS1115 | |||||
| Type | Single Cylinder, Horizontal, 4-Strokes, Direct Injection | Single Cylinder, Horizontal, 4-Strokes, Direct Injection | |||||
| Bore x Strode (mm) | 110x115 | 115x115 | |||||
| Rated Rotary Speed （r/min） | 2200 | 2200 | |||||
| Rated Power(Kw) | 13.2 | 14.7 | |||||
| Max. Torque （N · m） | 68.8 | 76.6 | |||||
| Max. Torque Rotary Speed （r/min） | 1760 | 1760 | |||||
| Fuel Consumption Ratio （g/Kw · h） | ≤244.8 | ≤245.8 | |||||
| Oil Consumption Ratio （g/Kw · h） | ≤2.72 | ≤2.78 | |||||
| Cooling Type | Water Cooling, circulation | Water Cooling, circulation | |||||
| Contact Name: | Mr Tony Niu | Contact Email: | 13****3@163.com |
| Contact Job Title: | Manager | Contact Mob: | 135***993 |
| Contact Tel: | Contact Fax: | ||
| Address: | Website: |
Shifeng Group was established on 18th May, 1993.The group covers an area of 333 hectares, its total assets is 6 billion Yuan RMB and it has 30,000 employees. The leading products includes 3-wheel trucks, low-gear trucks, light trucks, electric automobiles, tractors, engines, combined harvester and tyre in 5 industry gardens. We exported our products to more than 50 countries in Africa, Europe and America. For example, USA, Mexico, Indonesia, Pakistan, Bangladesh and Albania, etc.
