2021 New Class C Motorhome for Ford Transit Chassis
Auto,Parts & Accessories ATVs UTVs & RVs,Campers
MOQ:1 Set(s)
Payment Method : L/C T/T
Keywords:RV Caravans motorhome camper
| Product Category: | Auto,Parts & Accessories > ATVs UTVs & RVs,Campers | Trademark: | |
| Product Package: | Specifications: | ||
| Place of Origin: | Port: | Wuhan, Shanghai |
1. Highlight
* Aluminium Alloy body plus sandwich composite plate
* Euro 6 Emission Standard, 6-speed manual automatic combined transmission
* Unique lifter roof design: driving height below 2.3 meters,reduce air resistance and drive safely, park in underground garage in city freely
* The most flexible type C RV, with pop-up roof and side extender
2. Specification (Ford Transit Chassis)
Type | New Class C motorhome |
Rated Passengers | 4, 5, 6 |
Outside Dimension (L×W×H) (mm) | 5995*2250*2280 |
Curb Weight (kg) | 2892 |
G.V.W (kg) | 3300 |
Wheelbase (mm) | 3300 |
Front Tread (mm) | 1736 |
Rear Tread (mm) | 1720 |
Tire Type | 215/75R16LT |
Engine Type | ECOBOOST4G20B6L |
Engine Displacement | 2.0T |
Max power/rpm (KW/rpm) | 149/5500 |
Max torque/rpm (N.m/rpm) | 300/3000 |
Engine | Turbocharged |
Emission standard | Euro 6 |
Transmission | 6AT |
Maximum Speed (KW/h) | 156 |
Fuel tank capacity (L) | 80 |
Fuel consumption (L) | 8.8 |
Suspension system (front/rear) | Macpherson independent suspension/leaf spring suspension |
Steering wheel | adjustable |
Steering gear | Hydraulic power assisted steering system |
Driving | front engine front wheel drive |
Driving Brake system | double circuit hydraulic braking |
Breaking system | disc |
RV specification
Al-Alloy body+sandwich composite plate | Electric transmission ventilation window with turning function |
12V DC four column synchronous electric lift cylinder | Caravan special skylight |
Folding outdoor waterproof insulation curtain | floor air conditioner with Cold and warm integrated |
Single opening rear door (with screen door) | Water thermal insulation system |
Side sliding window (with curtain and screen) | Caravan central control system |
Body appearance is white with color bar painting | Caravan special Refrigerator (49L) |
Wall and sofa embellish Environmental leather | 800W Electric stove |
King size bed up on the driving area 2000mm×1400mm | reverse camera |
deluxe double seats | LED atmosphere lamp inside |
Massage chair | 110Ldouble temperature water purification tank |
single bunk (1000mm×2100mm) | 45LSewage tank |
Interior 19 inch flip TV | RV special water pump |
External 22 inch flip TV | Caravan special water inlet |
Fixed Table | circular sink |
The high-end cabinet table board, composite shape of cabinet and locker | Shower Unit |
External pull out burner gas stove | External faucet |
5L gas cylinder | 3000W charging inverter integrated machine |
External seasoning box | 400Ah LFP battery |
Storage area under the bed | 220V AC outlet |
Caravan special zip mode shower | 220V city electric fast interpolation,15m external cable |
Portable electric toilet | 300W flex solar panels on the roof |
Tail traction device (without seven-core socket) | external manual sunshade with LED light |
3. Product Display
King-size bed 2000x1400mm up on the driving area, deluxe double seats, optional single seat with heating function, vertical double bed with side extender, and rear independent bathroom
4. Our Company
Qixing Group is a professional RV manufacturing enterprises, Qixing has multiple production lines for RV, including mould processing, stamping, robotic automatic welding, cathodic electrophoresis, carpentry decoration, interior trim, wire harnesses, etc... The anti-aging test station, rain test station, vehicle test line, and special road test line for vehicle interior parts ensure that every RV leaves the factory is carefully and rigorously tested.
5. Our Service
1. OEM Manufacturing welcome: Product, Package...
2. Sample order
3. We will reply you for your inquiry in 24 hours.
4. after sending, we will track the products for you once every two days, until you get the products. When you got the goods, test them, and give me a feedback. If you have any questions about the problem, contact with us, we will offer the solve way for you.
6. FAQ
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 20 to 40 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship?
A: 1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
