yantai xinpeng AISI 1045 1020 BKS Mechanical using Precision Cold rolled steel Tube
Manufacturing & Processing Machinery Engineering & Construction Machinery
MOQ:5 Ton(s)
Payment Method : L/C T/T
Keywords:Cold rolled steel Tube steel Tube yantai xinpeng cold rolled tube mechanical steel tube
| Product Category: | Manufacturing & Processing Machinery > Engineering & Construction Machinery | Trademark: | YTXP |
| Product Package: | BUNDLE PACKAGE WITH THE WOVEN BAG OUTSIDE | Specifications: | SIZE 105*90 108*95 111*95 140*120 130*110 123*105 110*90 146*125 165*140 160*135 176*150 AND SON ON |
| Place of Origin: | YANTAI, CHINA | Port: | YANTAI/QINGDAO |
yantai xinpeng AISI 1045 1020 BKS Mechanical using Precision Cold rolled steel Tube
Size | ID*OD | (mm) | These sizes have stock, | ||
40*50 | 90*110 | 140*170 | 60*45 | 120*140 | 180*205 |
40*55 | 95*110 | 145*170 | 70*57 | 125*140 | 90*105 |
50*60 | 95*115 | 150*170 | 90*80 | 125*145 | 70*85 |
50*65 | 100*110 | 150*175 | 102*90 | 125*150 | 70*90 |
55*70 | 100*114 | 150*180 | 50*40 | 130*150 | 75*90 |
60*70 | 100*115 | 155*180 | 55*40 | 130*155 | 140*165 |
60*75 | 100*120 | 160*175 | 180*210 | 130*160 | 70*80 |
60*78 | 100*125 | 160*180 | 180*215 | 135*160 | 70*82 |
63*73 | 105*125 | 160*185 | 180*220 | 140*160 | 165*205 |
63*75 | 110*125 | 160*190 | 185*205 | 80*100 | 170*200 |
63*76 | 110*130 | 160*195 | 185*215 | 80*92 | 85*100 |
63*78 | 115*130 | 165*190 | 185*220 | 80*95 | 180*200 |
65*80 | 115*135 | 165*140 | 140*120 | 146*125 | 30*25 |
Precision tubes are delivered in following conditions
BK (+C) Cold finished/hard (cold finished as drawn).
No heat treatment after last cold forming process.
BKW (+LC) Cold finished/soft
After last heat treatment there is a light finishing pass (cold drawing).
BKS (+SR) Cold finished/stress relieve annealed.
After the final cold forming process the tubes are stress relieve annealed.
GBK (+A) Annealed
After the final cold forming process the tubes are annealed in a controlled atmosphere.
NBK (+N) Normalized.
After the final cold forming process the tubes are annealed above the upper transformation point in a controlled atmosphere.
Tests: 100% eddy current test, chemical and mechanical inspection, size checking and others
Material chemical composition of cylinder barrel:
Material | Chemical composition | ||||||
C (%) | Si (%) | Mn (%) | P (%) | S (%) | Cr (%) | Mo (%) | |
SAE1020/AISI1020/S20C material : 20# | 0.17-0.24 | 0.17-0.37 | 0.4-0.7 | 0.030 max | 0.025 max | - | - |
SAE1026/25Mn | 0.22-0.28 | 0.15-0.35 | 0.6-0.9 | 0.030 max | 0.030 max | - | - |
SA1045/S45C,CK45,C45E | 0.42-0.50 | 0.17-0.37 | 0.5-0.8 | 0.030 max | 0.025 max | - | - |
ST52/ST52.3/ST52.4/E355/Q345B | 0.22 max | 0.55 max | 1.60 max | 0.025 max | 0.025 max | - | - |
27SiMn GB standard | 0.24-0.32 | 1.1-1.4 | 1.1-1.4 | 0.035 max | 0.035 max | - | - |
SAE4130/34CrMo | 0.28-0.33 | 0.15-0.35 | 0.4-0.6 | 0.035 max | 0.035 max | 0.9-1.2 | 0.15-0.30 |
SAE4140/42CrMo | 0.38-0.45 | 0.4 max | 0.6-0.9 | 0.035 max | 0.035 max | 0.9-1.2 | 0.15-0.30 |
