Prefab 20ft Prefab Cheap Expandable Container House

Characters:
(1). Good ability to assemble and disassemble for several times without damage.
(2). Could be lifted, fixed and combined freely.
(3). Heatproof and waterproof.
(4). Cost saving and convenient transportation (Each 4 container house can loaded in one standard container)
(5) Service life can reach up to 15 - 20 years
(6) We can provide the service of installation, supervision and training by extra.
Technical Parameter:
(1).Size: GP20, GP40 and HP40 of shipping container
(2).Wind Resistance: Grade 12
(3).Wall permitted loading: 0.6KN/ m2
(4).Ceiling Permitted live loading: 0.5 KN/m2
(5).Wall Coefficient of thermal conductivity: K=0.442W/mk
(6).Ceiling Coefficient of thermal conductivity: K=0.55W/ m2K
Dimensions and Weight
(1).Inner length /external length :5.81m/6.06m
(2).Inner width /external width: 2.188m/2.438m
(3).Inner height/external height:2,410m/2.591m
(4).Weight: 2000kg per unit
Steel framework
(1).Material: steel material Q345, thickness: 3.5mm,for top beam frame. Base beam frame and column.
(2).Surface working: epoxy painting,two bottom and two surface.
(3).Fittings: 8 standard container corner mould fittings PVC standard rainwater pipe
(4).Forklift openings: size 100*250mm, distance is 1200mm


Floor
(1).External wainscot: Flat galvanized color steel sheet, 0.5mm thickness
(2).Floor structure: Girder made of 3.5mm steel. The purlin is C section steel. dimension 60x40x1.5mm.
(3).Warm proof Insulation layer:
(a)75mm rock wool
(b)18mm bamboo plywood
(c)2.0mm PVC floor leather for living rooms floor;
Ceiling Construction:
(1).Roof exterior layer: 1.2mm steel plate with epoxy painting
(2).Warm proof insulation filling: 75mm rockwool between C section purlins;
(3).Inner wainscot: 8mm OSB board with 12mm PVC decoration board.
(4).Roof water drain: 4 PVC rainwater pipes in the corner pillars, diameter 50mm
Walls
(1).Panel width: 1150mm; panel total thickness: 75mm, five panels fit into the long side and two panels fit into the short side.
(2).Common room wall: 75mm rockwool  0.4/0.4mm Galvanized . Steel on both side .
Desity of Rockwool: 120Kg/m3
(3).Galvanize window opening on the wall if needed.
Door
(1).External door: Insulated with opening dimension 950*2100mm, furnished with lock
with 3keys.
(2).Inner door: Insulated steel door.

Window material: PVC window with fly screen. Double glass, 4mm glass.
 Electrical fittings option
Electrical wire, 2.5mm2 for lighting system, and 4mm2 for AC units.
Main outlet and input industrial socket with 32A.
3 pcs 16A five hole universal socket.
2 pcs double tube fluorescent lamp, 220V,50-60HZ
1 pc Single Switch, Honyar brand, with junction box
1 pc Electrical distribution box, box+breakers+earth leakage protective device
Our Services
1. Professional design and engineering team: Full solution for site camp design. We could make the design for whole camp as per your requirement.
2. Procurement and Manufacture for all material for prefabricated building. We have a professional procurement team to make sure all the materials are with good quality. And our factory operation under ISO standard, to make sure the fabrication works with high technology.
3. Site management & Installation supervision, We could send our engineers to help for the installation supervision, you just need to prepare a team which know normal construction works will be OK.

Company Information

Founded in 1993, Lida Group is one of the most powerful manufacturers of steel structure building, steel warehouse,
poultry house, aircraft hangar, prefab house, porta cabin, affordable housing, container house and steel villa in China.
 We have been awarded ISO9001, CE and SGS certificates.
Our daily capacity can reach 5000 square meters and this is how we manage it.
750 employees, include 50 engineers and 200 supervisors for overseas projects.
73000 square meters factory space.
3 production lines for steel structure warehouse series, 3 production lines for prefabricated house series,
3 container house production line and 1 steel villa series production line.

Lida Group has three Subsidiaries, they are Weifang Henglida Steel Structure Co., Ltd,
 Qingdao Lida Construction Facilities Co., Ltd. and Shouguang Lida Prefabricated house Factory.
And six overseas branch offices, they are Saudi Arabia Riyadh office, Qatar Doha Office, Maldives Male office, Sri Lanka Colombo office, Malaysia Office and Zambia Lusaka office.

We have exported more than 130 countries since foundation.
Lida Group is a comprehensive enterprise of design, producing and installation.
