Features:Universal dry cutting blades,versatile used in cutting different materials.Can be cold,hot press or laser welded.

Machinery:Angle grinder,circular saw,masonry saw,table saw.

Applications:Concrete,Brick,Clay paving,General construction materials.

Item No.	Outer   Diameter		Arbor	Segment      Width(mm)	Segment     Height(mm)	No.of     Segments
	mm	inch
WD-501	105	4	16/20/22.23	1.8	7/10	8
WD-502	110	4.3	16/20/22.23	1.8	7/10	8
WD-503	115	4.5	16/20/22.23	2.0	7/10	9
WD-504	125	5	16/20/22.23	2.0	7/10	9
WD-505	150	6	16/20/22.23	2.0	7/10	12
WD-506	180	7	22.23/25.4/30/DM	2.2	7/10	14
WD-507	200	8	22.23/25.4/30/DM	2.4	7/10	16/18
WD-508	230	9	22.23/25.4/30/50/DM	2.0	7/10	18
WD-509	250	10	22.23/25.4/30/50	2.8	8/10/12	18
WD-510	300	12	22.23/25.4/30/50	3.0	8/10/12	21
WD-511	350	14	22.23/25.4/30/50	3.2	8/10/12	24
WD-512	400	16	22.23/25.4/30/50	3.4	8/10/12	28
Different arbor   sizes and segment specifications are available upon request.
