The basin rubber bearing is a new type of bridge bearing composed of steel component and rubber. It has the characteristics of large bearing capacity, large horizontal displacement, flexible rotation and so on. It is suitable for long-span Bridges with bearing capacity of more than 1000KN.

The basin rubber bearing is divided into fixed bearing and movable bearing. The movable basin rubber bearing is composed of an upper bearing plate, a polytetrafluoroethylene plate, a pressurized rubber block, a rubber sealing ring, a middle bearing plate, a steel hoop ring, a lower bearing plate and a lower bearing plate. A fixed bearing can be formed by combining upper and middle bearing plates or connecting plates with upper and lower bearings.

Product Description:

1 Product name: highway bridge basin bearing; Basin bearing; Steel bearings; GPZ bearing

2 Product classification: fixed support -GD; Unidirectional movable support -DX; Bidirectional movable support -SX.

3 Applicable temperature: normal temperature type -25℃~60℃; Cold resistant type -40℃~-60℃.

4 Main materials: natural rubber, neoprene rubber; Cast steel cover plate; Cast steel base; Intermediate cast steel plate; Reinforced steel plate; Stainless steel plate; Anchor bolt; The skateboard; Silicon grease. Dust cover.

5 Load class: 100KN-90000kN.

6. Performance index: vertical Angle ≥40 '; Vertical bearing capacity KN 1000-90000kN, friction coefficient at room temperature ≤0.04 cold resistance ≤0.06; Displacement ±50~±250mm.

7. Specific description: The function of the bridge support is to transmit static load and dynamic load, braking force and wind power to the pier and abutment. The structure of the support must be able to meet the displacement and torsion caused by traffic, temperature change, earthquake, prestress, shrinkage and creep, etc. It can be seen that the support is the most important component in the bridge, and its quality requirements must be of high standard.

The basin rubber bearing is a new type of bridge bearing composed of steel component and rubber. It has the characteristics of large bearing capacity, large horizontal displacement, flexible rotation and so on. It is suitable for long-span Bridges with bearing capacity of more than 1000KN.

The basin rubber bearing is divided into fixed bearing and movable bearing. The movable basin rubber bearing is composed of an upper bearing plate, a polytetrafluoroethylene plate, a pressurized rubber block, a rubber sealing ring, a middle bearing plate, a steel hoop ring, a lower bearing plate and a lower bearing plate. A fixed bearing can be formed by combining upper and middle bearing plates or connecting plates with upper and lower bearings.

盆式橡胶支座是钢构件与橡胶组合而成的新型桥梁支座。具有承载能力大、水平位移量大、转动灵活等特点，适用于支座承载力为1000KN以上的大跨径桥梁。

   盆式橡胶支座分固定支座与活动支座。活动盆式橡胶支座由上支座板、聚四氟乙烯板、承压橡胶块、橡胶密封圈、中间支座板、钢紧箍圈、下支座板以及上下支座连接板组成。组合上、中支座板构造或利用上下支座连接板即可形成固定支座。

产品描述：

1产品名称：公路桥梁盆式支座；盆式支座；钢支座；GPZ支座

2 产品分类：固定支座-GD；单向活动支座-DX；双向活动支座-SX。

3 适用温度：常温型 -25℃~60℃；耐寒型 -40℃~-60℃。

4 主要材料：天然橡胶，氯丁橡胶；铸钢盖板；铸钢底座；中间铸钢板；加筋钢板；不锈钢板；锚栓；滑板；硅脂；防尘罩。

5 荷载等级：100KN-90000KN。

6 性能指标：竖向转角≥40′；竖向承载力KN 1000-90000KN，摩擦系数 常温≤0.04 耐寒≤0.06 ；位移量±50~±250mm。

7具体描述：桥梁支座的功能是将静载和动载力、制动力和风力传送到桥墩和桥台。支座的结构必须能满足由交通、温度变化、地震、预应力、收缩徐变等产生的位移和扭转。由此可见，支座是桥梁中最重要的元件，其质量要求必须是高标准的。

   盆式橡胶支座是钢构件与橡胶组合而成的新型桥梁支座。具有承载能力大、水平位移量大、转动灵活等特点，适用于支座承载力为1000KN以上的大跨径桥梁。

   盆式橡胶支座分固定支座与活动支座。活动盆式橡胶支座由上支座板、聚四氟乙烯板、承压橡胶块、橡胶密封圈、中间支座板、钢紧箍圈、下支座板以及上下支座连接板组成。组合上、中支座板构造或利用上下支座连接板即可形成固定支座。
