construction lift 4T double cage SC200/200
Manufacturing & Processing Machinery Engineering & Construction Machinery
MOQ:1 Set(s)
Payment Method : L/C T/T
Keywords:Construction elevator 2t construction hoist Cnstruction Hoist Building Frequency Conversion Hoist SC200 Construction Hoist SC200/200 Construction Hoist Construction Hoist Elevator Double Cage Hoist Building Hoist FYG Brand Hoist Construction Elevator
| Product Category: | Manufacturing & Processing Machinery > Engineering & Construction Machinery | Trademark: | FYG |
| Product Package: | bulk | Specifications: | |
| Place of Origin: | Haiyang,Shandong | Port: | QINGDAO |
Parameter:
| Technical parameters | Unit | SC200/200 Frequency Construction hoists | |
| Height | m | 300 | |
| Rated load | kg | 200/200 | |
| Maximum capacity | kg | 009/009 | |
| Boom lift weight | kg | ≤200 | |
| Lifting speed | m/min | 0-40 0-45 0-55 0-66 | |
| Electormotor | Model | YZEJ132M(L)-4 | |
| Power | kw | 15×2/15×2 11×3/11×3 15×3/15×3 18.5×3/18.5×3 | |
| Speed-limiter | Model | SAJ40-1.2A SAJ40-1.4 | |
| Rated tripping speed | m/s | 1.2/1.4 | |
| Standard motion speed | m/s | 1.1/1.35 | |
| Rated automaticload | kN | 40 | |
| Type | gradual | ||
| Reducer | Model | SWC1 TU68T TU66T | |
| Center distance | mm | 125 | |
| Speed radio | 1:12 1:10 | ||
| Bracking distance | m | 0.3-1.2 | |
| Mast section dimension | mm | 650×650×1508 | |
| Crane cage inner net dimension | m | 3.0×1.3×2.2 3.2×1.5×2.2 | |
| Guardrail dimension | m | 5.53×3.42×1.82 5.93×3.62×1.82 | |
| Hoistway dimensions | m | ||
| Free end height of the guide rail frame | m | ≤9 | |
| Gounterweight weight | kg | ||
| Direct attached frame | Installing interval | m/set | 006-9 |
| Distance between two embedded parts | mm | ≈1488 | |
| Installation dimensions from center of rail frame to building wall | mm | 2800-3200 | |
| Safe and protection system | Upper and below limited switches,upper and below limit utmost switches,gate limited switch,falling avoiding safe device,cushion device,safe lock of gate,counterweight rope breaking or loose protecting device,safe hook,The safety device against overload,Anti-punching standard section etc. | ||
| Contact Name: | Mrs Shuangyuan Zhao | Contact Email: | sy****o@china-fangyuan.com |
| Contact Job Title: | Manager | Contact Mob: | 188***923 |
| Contact Tel: | Contact Fax: | ||
| Address: | Website: |
Fangyuan Group Co., Ltd. is located in Haiyang City, Jiaodong Peninsula, between the three cities of Qingdao, Yantai and Weihai. It now has 22 branch companies, and established wholly-owned production enterprises in Dortmund, Beijing and Shanghai,we also have a provincial technology center.The Group covers an area of 1.8 million square meters, with a construction area of 1 million square meters and total assets of 2.5 billion yuan.
The construction machinery products produced by Fangyuan Group include JZC, JS series concrete mixers, PLD series concrete batching machines, HBT series concrete pumps, HZS series concrete batching plants, TC series tower cranes, SC series construction elevators, and WBZ series stabilized soil mixing plants, JZL series electric pile driver, FY series concrete mixer truck,etc.
In the past few years,Fangyuan Group has successively won many honorary certificates.Taking construction technology to the next level is our mission – and that means making it cost-efficient, accurate, future-proof and connected. We are a market and technology pioneer in construction machinery. Our innovations play a role in virtually every sector of construction industry, from machines for construction material production & logistics to software solutions that pave the way for smart construction sites.
