Filter

AC Filter(AC50/60 Hz), EMG Filter (25 Hz/35 Hz (-3 dB)), DFT Filter, Low-pass Filter

Standard sensitivity

10mm/mV±5%

Specification of recording paper

80 mm(W)×20 m(L) high-speed thermal paper

Time base selection(paper speed)

5 mm/s, 6.25 mm/s, 10 mm/s, 12.5 mm/s, 25 mm/s, 50 mm/s, error: ±5% within 0.2s～2.0s

Gain control(sensitivity)

2.5, 5,10, 20, 40, 10/5, 20/10mm/mV, accuracy is ±5%; Standard sensitivity: 10 mm/mV±0.2 mm/mV

Rhythm record

Record setup according to rhythm record format and mode, automatically measure and analyze. Manual record: record according tomanual record format.

Auto record

Record setup according to auto record format and mode, automatically change leads, automatically measure and analyze.

Manual record

HR, PR interval, P Duration, QRS Duration, T Duration, QT/QTc interval, P/QRS/T Axis, R(V5) amplitude, S(V1) amplitude, R(V5)+S(V1) amplitude

Recording way

Thermal printing system

Product safety type

Class I type CF defibrillation-proof applied part

Polarization resistance voltage

±950 mV

Standard configuration

1)A lead cable

Physical characteristic

Working environment Temperature: 5℃~40℃ Relative humidity: 25%~95%(non-condensing)

Function

1)High resolution thermal-array output system(8 dots/mm), no adjustment required. Frequency Response is up to 150Hz. 2)Sync
collection for 12-lead ECG, support routine 12-lead and Cabrera-lead waveform display. Get high-quality ECG waveform via AC
filter, DFT filter, EMG filter and Low-pass Filter of ECG signal. 3)Display 3/6/12 - lead ECG waveform, print mode, sensitivity,
paper speed, filter status, etc. on one screen, convenient for contrastively diagnosing. 4)Support for auto 1×12, auto 1×12+1,
auto 2×6, auto 2×6+1, auto 3×4, auto 3×4+1, auto 4×3, auto 3-2+1, auto 3-2, rhythm 4, rhythm 3, rhythm 2 and manual. The printed
content contains time, paper speed, sensitivity, calibration signal, name of lead, filter state and patient’s information.
Information including printed waveform length, output measurement parameter, diagnostic conclusion, superposition QRS waveform,
histogram, trend chart and interval list, can be set, and with time print function, which meets different requirements. 5)With the
functions of auto-measurement and auto-interpretation for routine ECG parameters, provide measurement results for HR, PR interval,
P Duration, QRS Duration, T Duration, QT/QTc interval, P/QRS/T Axis, R(V5), S(V1) and R(V5)+S(V1), etc. and auto-diagnosis
conclusion, which reduces the doctor’s burden. 6)Rhythm lead can be selected freely, convenient to observe abnormal heart rhythm.
7)The subject’s clinical information (such as, ID, Name, Age, Sex, Height, Weight, etc.) can be entered. 8)1000 cases can be
stored by the built-in memory, convenient for case review and statistic. 9)Multi-language (Chinese, English, Turkish, Portuguese,
German, Russian and Kazakh, etc.) interface and report. 10)Power supply: AC/DC (which can adapt AC 50/60Hz), with built-in
rechargeable lithium battery, charging circuit, perfect over-current and over-voltage protection circuit. 11)External USB
keyboard, code scanner, printer and USB storage device can be connected.

Note

The device sold to the countries and regions that have certification requirement does not support automatic analysis and diagnosis
function.
