High Pressure Hydraulic Hose
Print,Pack,Plastic Rubber & Plastics Products
MOQ:500 Meter(s)
Payment Method : L/C T/T
Keywords:high pressure hydraulic hose high pressure rubber hose high pressure Oil hose gasoline hose oil hose wire braided rubber hose wire spiral hydraulic hose hydraulic hose hydraulic hose assembly
| Product Category: | Print,Pack,Plastic > Rubber & Plastics Products | Trademark: | DAYI Hose |
| Product Package: | inside plastic and outside woven bag | Specifications: | 1/4" ~ 2" |
| Place of Origin: | China | Port: | tianjin |
SAE100R1AT / DIN EN853 1SN HIGH PRESSURE HYDRAULIC HOSE
(Wrapped Cover / Smooth Cover )
CONSTRUCTION:
This hose consists of an inner tube of oil synthetic rubber, single wire braid reinforcement, and an oil and weather resistant synthetic rubber cover.
APPLICATIONS:
Hose range suitable to carry hydraulic fluids such as glycol, mineral oils, fuels lubrication, emulsion, hydrocarbons Etc.
WORKING TEMPERATURE:
From -40℃ up to +100℃
Hose Size(inch) | HOSE ID(mm) | HOSE OD(mm) | Woring Pressure(Bar) | Burst Pressure(Bar) |
| 1/4 | 6.4 | 13.4 | 225 | 900 |
| 5/16 | 7.9 | 15.0 | 215 | 850 |
| 3/8 | 9.5 | 17.4 | 180 | 720 |
| 1/2 | 12.7 | 20.6 | 160 | 640 |
| 5/8 | 15.9 | 23.7 | 130 | 520 |
| 3/4 | 19.0 | 27.7 | 105 | 420 |
| 1 | 25.4 | 35.6 | 88 | 350 |
| 1 1/4 | 31.8 | 43.5 | 63 | 250 |
| 1 1/2 | 38.1 | 50.6 | 50 | 200 |
| 2 | 50.8 | 64.0 | 40 | 160 |
