1. Horizontal centrifugal slurry pump is adoptable to transfer slurry containing high abrasive, high corrosive and high density suspended solid particles.




2. Typical Application:

● Chemical Process

● Minerals benefication

● Paper and Pulp

● Mill Discharge

● Bottom Boiler and Fly Ash

● Cyclone Feed

● Power Plants

● Concentrated brine

● other industries

2. Features:

● Replaceable wear-resistant metal liners, impellers &volute liners are made of wear-resistant metal (such as 05A, 49A, and other high chrome metal or rubber).

● Bearing assembly uses cylindrical structure, adjusting the space between impeller & front liner easily, being removed completely when being repaired. Grease lubrication.

● The impeller can be 2--6 blades ones, making the pump more effective. And the pump can achieve in excess of 87% in the best efficiency area.

● Shaft seal could use the packing seal, expeller seal and mechanical seal. One pump also can be use expeller seal accompany with packing.

● The discharge outlet can be positioned at intervals of 45 degrees by request and oriented to any 8 positions to suit installations and applications.

● This pump can be installed in multistage series to meet the delivery for long distance.

● Drive types: direct coupling drive(DC), V belt drive(CR, CV, ZV, CL), etc.
