Portable Syngas Analyzer

Oil & Gas Oil and Gas Equipment

FOB Price:US$ 3,000.00 / Piece(s)

MOQ:1 Piece(s)

Payment Method : L/C T/T D/P

Keywords:Portable Syngas Analyzer Gas analyzer Oxygen analyzer

Add to Favorites

Product Category: Oil & Gas > Oil and Gas Equipment Trademark:
Product Package: box Specifications:
Place of Origin: wuhan, China Port: Shanghai

Product Introduction
The equipment uses imported NDIR non-spectroscopy infrared and ECD electrochemical technology, which is mainly used to measure the volume concentration of CH4, CO2, H2S, O2, H2, CO in biogas.  The product has high measurement accuracy, simple structure, convenient operation and good practicability. Mainly used in the fields of landfill, anaerobic fermentation production process, sewage treatment and CDM metering.

Characteristics
1.One instrument simultaneously measures the volume concentration of CH4, CO2, H2S, O2, H2, CO in Syngas.

2.The instrument adopts 5 inch TFT LCD touch screen for human-computer interaction, digital/curve display real-time concentration, simple operation and use.

3.Aluminum alloy material, compact and easy to carry (270X136X136mm).

4.Save historical data, adjustable time interval, USB interface export data table.

5.Soft start power switch, intelligent management of battery power, to avoid the instrument working under low power conditions.

6.Calibration menu and alarm value setting are controlled by password to prevent mis-operation.

7.One-key recovery of "factory settings", eliminating the need to return to the factory for repair after misuse.


Parameters


Main Accessories
Portable sample gas washing equipment for dust/tar/moisture removal, including:

●2 washing towers to wash tar and dust;

●1 filter with activated carbon;

●1 precision filter, replaceable 0.3μm filter element;

●1 flow regulator, used to control the intake air flow
