The function of the KB1000 transformer core grounding current tester is compact and portable, the whole text graphic interface is carried, and the operation anti-interference ability of the touch screen is extremely strong, which ensures accurate and reliable data

with built-in large capacity lithium battery, and is convenient to use double-circle CT balance current special calipers on the spot.

The operation is convenient, the test program is simple and efficient, the instrument measures automatically, and the waveform display application of this instrument has high measurement accuracy and simple operation. It is suitable for testing the leakage current of iron cores and clamps of substations and power plants as transformers, reactors and other electrical equipment. Using the latest CT double-layer magnetic shielding technology and zero-input impedance current measurement technology, it is almost not affected by the interference of external magnetic field and electric field, which ensures the high precision, high stability and high reliability of acquisition and measurement.

According to the power industry standard of our country: DLT596 "Preventive Test Code for Power equipment", the requirements for power transformers are as follows: "the grounding current of iron core in operation is generally no more than 0.1A". The transformer core in normal operation is grounded at a single point. If two or more points are grounded at the same time, a current loop will be formed between the core and the earth, and the maximum current can reach dozens of amperes, which will cause local overheating or even burn out of the core. Finding the latent faults of the transformer as soon as possible is the main means to ensure the safe operation and normal maintenance of the transformer. Under conditional conditions, the iron core grounding current can be monitored on-line. It is specially suggested that this instrument is dual-purpose and has a built-in large-capacity lithium battery. when the instrument is not in use for a long time, it is recommended to charge and maintain it every other month to avoid battery self-discharge depletion and damage to the battery.
