Envsin Aging Test Machine Manufacturer with Cecertification

Manufacturing & Processing Machinery General Industrial Equipment

FOB Price:US$ 1,200.00 / Piece(s)

MOQ:2000 Piece(s)

Payment Method : L/C T/T Western Union Paypal Money Gram Others

Keywords: Aging Test   Aging Test Machine

Inquire


Add to Favorites

Product Category: Manufacturing & Processing Machinery > General Industrial Equipment Trademark:
Product Package: Specifications:
Place of Origin: Port: Shenzhen

Basic Info.

Model NO.
EWG2003/EWG3003/EWG2006/EWG3006/EWG2010/EWG3010
Type
Aging Test Chamber
Maxcapacity
Temp.Range: Rt~300 Degree
Accuracy Grade
0.5
Load Way
Electronic Load
Loading Method
Static Load
Display
Digital
Control
Computer Control
Weight
0-100Kg
Power Source
AC220V AC380V
Oil Cylinder Position
None
Test Area Valume
600L
Temp. Range
R.T. 20~300 Dge C
Temp. Fluctuation
+/-0.1~0.8 Dge C
Temp. Uniformity
+/-0.5~2.0 Dge C
Temp. Deviation
+/-0.5~2.0 Dge C
Heat up Time
50min (R.T. to 200 Dge C)
Test Area Dimension(W*D*H)
850*700*1000mm
Exterior Dimension(W*D*H)
1250*980*1850mm
Power
AC380V ±10%, 50Hz, 3/N/PE
Standard Version
2 Stainless Steel Shelves
Trademark
Envsin
Specification
ISO9001 & ISO14001
Origin
Guangdong China
HS Code
90321000

Product Description



Specifications



ModelET4008
ET7008ET4018
ET7018ET4034
ET7034ET4060
ET7060ET4100
ET7100

Test Area Volume (L)
80
190
335600
1000


Temp. Range (oC)-40+180-70/+180-40/+180-70/+180-40/+180
-70/+180-40/+180-70/+180-40/+180-70/+180

Temp. Fluctuation (oC)
±0.1-±0.5




±0.1-±0.5





















Temp. Uniformity (oC)
±0.5-±2.0




±0.5-±2.0






















Heating Rate (oC/min)3.3
3.34.1
3.53.5
3.04.0
4.03.2
3.5

Cooling Rate (oC/min)3.0
2.73.5
3.03.0
3.32.5
2.52.5
2.3



















Test Area Dimension
400
580580800
1100



















W×D×H (mm)
400
450765800
950




500
750750950
950



















Exterior Dimension
650
8708701090
1390


W×D×H (mm)1000
155018601960
2155



1750
180018001995
1995


Max. Load (KG)
5
20
5070
100


Cooling Methods





Air-Cooled




























Features

Intelligent 32 bit measuring and control system with colorful screen. Interface USB andEthernet.

Programmable power outlet with 4-CH. ON/OFF output control, to ensure safety. Patented air circulation system improves test's accuracy.

Independent thermal protector and sensors keep test specimen off over temperature,breezeless and smog.

Network video monitoring is synchronized with test data. Without defrosting, during operating in low temperature.


Optional Accessories

Independent sensor for protecting test specimen

(compliant with NE60519 -2.1993)

Lead through Φ100mm

Drier filter for compressing air

Nitrogen gas auxiliary device

Modular fabrication technique. APP mobility management.

Environmental servo refrigerant flow control for energy saving and quick heat-up/cool-down rate.

Uniquely operation mode makes testing zone's temperature back to R.T after test, which protects sample status. Automatic reminder of maintenance time of equipments and software of fault records.

Optional remote service function and video CD of equipment operation.

Air-Cooled Unit

Accessory bag

Software for Internet-based management

Video monitor system

APP for mobile management

Standard Accessories




3 Power outlets for test specimen

2Silicon stoppers for lead through






Left and right lead through with Φ50mm

2Stainless steel shelves


Achine type: Voltage Three-phase 380V ± 10 /Rated Current
Total power: 15.5KW
Quality assurance: In order to further improve the company's product and company management level, to provide users with high brand, high quality, high efficiency, world-class high-service environmental testing equipment, the company strictly in accordance with IS09001: 2008 version of the standard quality assurance system operation.
Address: Factory address: Gongye 2nd Road , Langzhou Industry Area, Changping Town, Dongguan City, Guangdong, China
Certified by :Envsin equipment instrument co.,ltd
Authorized Person/Representative People :


Contact Name: Miss. Hui Li Contact Email: sa****s@imufogsins.com
Contact Job Title: CEO & Director Contact Mob: 158***562
Contact Tel: Contact Fax:
Address: Xinhewan field, Xiaodian District, Taiyuan City, Shanxi Province Website: www.envsin.com

Envsin is a leading environment test chamber manufacturer. Envsin Instrument Equipment Co., Ltd founded in 1997 and focus on the high-end environmental test chamber for about 20 years. As high-end environment test solution provider now mainly engaged in the international market : Mainly for national defence , the automobile enterprises , provide high -quality and high standards environmental test chambers and environmental reliability test plan for large projects.
