Growatt 3 phase grid tie 500kw solar inverter 10kw 20kw 30kw 40kw 50kw solar inverter- Product Details

ID:2004141884

Metallurgy,Chemicals & Energy Solar Energy,Environment & Recycling

MOQ:1.00 Set(s)

Growatt, 3 phase, grid tie, 500kw ,solar ,inverter ,10kw, 20kw, 30kw, 40kw, 50kw, solar ,inverter

L/CT/TD/PWesstern Union

Product Category

Metallurgy,Chemicals & Energy > Solar Energy,Environment & Recycling

Trademark

Product Package

Specification

Place of Origin

Port

Shanghai/Shengzhen

Overview

Quick Details

Supply Ability

Packaging & Delivery

Grid Tie Inverter

Equipments&Details

Datasheet	Growatt 10000UE	Growatt 12000UE	Growatt 18000UE	Growatt 20000UE
Input Data
Max.DC power	11000W	13200W	19800W	22000W
Max DC Voltage	1000V
Start Voltage	350V
PV Voltage Range	180-1000V
MPP Voltage Range	300V-1000V/600V
Full Load DC Voltage Range	400-800V
Number of MPP Trackers/ Strings per MPP Trackers	2/2
Max.Input Current	15A/15A	17A/17A	23A/23A	26A/26A
Max.Input Current per String	20A
Output (AC)
Rated AC output power	10KW	12KW	18KW	20KW
Max. AC output power	10KVA	12KVA	18KVA	20KVA
Max. apparent power	16A	19A	28.6A	32A
Max. output current Range	230V/400V184-275V
Power factor at rated power	1
Displacement power factor configurable	0~0.8leading 0~0.8lagging
THDI	<3%
AC connection	3/N/PE,3W+PE(Opt)
Efficiency
Max.efficiency	98.0%
Euro-eta	97.5%
MPPT efficiency	99.5%
Protection Devices
DC reverse polarity protection	yes
DC switch for each MPPT	yes
Output AC overcurrent protection	yes
Output AC overvoltage protection-varistor	yes
Ground fault monitoring	yes
Grid monitoring	yes
Integrated all-pole sensiteve leakage current monitoring unit	yes
General Data
Dimensions (W/H/D) mm	490/740/235	490/740/235	570/740/235	570/740/235
Operating temperature range	-25℃ ~ +60℃ with derating above45℃
Noise emission	<55dB(A)
Self-consumption(night)	<0.5W
Standby consumption	12W
Topology	Transformerless
Cooling concept	Smart cooling
Environmental protection rating	IP65
Altitude	2000m
Relative Humidity	0-100%
Features
DC connection	H4
AC connection	Screw teminal
Display	LCD
Interfaces	RS232/RS485/Ethernet/RF/WIFI
Warranty	5 years / 10 years
