Business Type: Manufacturer
Main Products:construction hoistmast climbing work platformself erecting tower cranebuilding maintenance unitconcrete placing boomwire mesh welding machinestirrup bending machinemortar plastering machinerebar splicing couplerfully hydraulic crawler multi-function drilling rigs
ID:2004303184
Category: Manufacturing & Processing Machinery Engineering & Construction Machinery
MOQ:1.00 Set(s)
Construction hoist lifting machine material and passengers hoistbuilding hoist
T/T
Remarks:
1. The recommended cage dimensions (L×W×H) (m) of our building hoist are:2.0×1.0×2.5, 2.5×1.3×2.5, 3.0×1.3×2.5, 3.2×1.5×2.5,3.8×1.5×2.5, 4.2×1.5×2.5 etc. We can also manufacture cages of the other sizes according to customer requirements.
2. Steel knitted mesh, galvanized sheet, punched sheet, figured sheet, and the others can be optional for customers to make cage body and door for the hoist.
3. Either painting or hot galvanized mast section and the tie-in/wall anchor can be optional for customers.
4. Both domestic and imported driving systems are available for the hoist.
5. Generally mast section size 650×650×1508 is used, other sizes e.g. 450×280×1508, 450×450×1508, 650×200×1508, 650×900×1508, 650×1508,800×800×1508, etc. are also available for your choice.
6. Any special requirements pls let us know.
SC200 & SC200/200 building lifter/elevator cage lift (for reference)
SPECIFICATIONS
Lifting Capacity Per Cage | 2000kg--22 passengers | ||
Cabin Inner Dimensions (LxWxH) | 3.2x1.5x2.3m | ||
Door Opening (WxH) | 1.42 m x 1.97 m | ||
Lifting Speed (m/min) | 0-36 | 0-45 | 0-63 |
Drive Motor (kw) | 2x9.2 | 2x11 | 3x11 |
Frequency Converter(kw) | 37 | 45 | 75 |
Full Load Starting Current(A) | 105 | 120 | 180 |
Full Load Working Current(A) | 70 | 80 | 120 |
Power Capacity (KVA) | 50 | 60 | 100 |
Cabin Weight (Moving Part)(kg) | 2100 | 2100 | 2350 |
Mast Section Dimension | 650 x 650 x 1508mm | ||
Mast Section weight | 125kg (single rack) 145kg (double rack) | ||
Foundation size(m) without driver cabin | 4.0x4.6 (double cabin) 4.0x2.8 (single cabin) | ||
Foundation size(m) with driver cabin | 4.0x6.0 (double cabin) 4.0x3.5 (single cabin) | ||
Base Unit Weight (Enclosure) | 1150 kg (double cabin) 910kg (single cabin) | ||
Power Required | 380V/415v, 50/60Hz | ||
Wall Tie Spacing | Adjustable Per Project Requirements | ||
Material | Galvanized Steel Sheet | ||
