Product name: stainless steel sanitary 90 welded elbow fittings elbow pipe fittings
Product name: stainless steel sanitary 45 welded elbow 45 degree elbow
stainless steel 45 degree elbow pipe fitting
Welded elbow /3A | ||||
| Size | L1 | D | R |
1″ | 15.8 | 25.4 | 38.1 | |
11/2″ | 23.8 | 38.1 | 57.2 | |
2″ | 31.8 | 50.8 | 76.2 | |
21/2″ | 39.7 | 63.5 | 95.3 | |
3″ | 47.6 | 76.2 | 114.3 | |
4″ | 63.5 | 101.6 | 152.4 | |
6″ | 94.7 | 152.4 | 228.6 | |
Welded elbow /DIN | ||||
| Size | L1 | D | R |
DN10 | 10.7 | 12.0 | 26.0 | |
DN16 | 14.5 | 18.0 | 35.0 | |
DN20 | 16.5 | 22.0 | 40.0 | |
DN26 | 20.7 | 28.0 | 50.0 | |
DN32 | 22.8 | 34.0 | 55.0 | |
DN40 | 24.8 | 40.0 | 60.0 | |
DN50 | 29.0 | 52.0 | 70.0 | |
DN66 | 33.2 | 70.0 | 80.0 | |
DN80 | 37.3 | 85.0 | 90.0 | |
DN100 | 41.5 | 104.0 | 100.0 | |
DN125 | 77.5 | 129.0 | 187.0 | |
DN150 | 93.2 | 154.0 | 225.0 | |
Welded elbow /ISO/IDF | ||||
| Size | L1 | D | R |
1″ | 13.9 | 25.4 | 33.5 | |
11/4″ | 15.7 | 32.0 | 38.0 | |
11/2″ | 20.1 | 38.1 | 48.5 | |
2″ | 25.1 | 50.8 | 60.5 | |
21/2″ | 34.6 | 63.5 | 83.5 | |
3″ | 36.7 | 76.2 | 88.5 | |
31/2″ | 42.9 | 89.0 | 103.5 | |
4″ | 52.6 | 101.6 | 127.0 | |
Connection Type: Welded
Material: SS304，SS316L
Standard: 3A, DIN, SMS, BS, RTJ, ISO, IDF, DS, INCH etc
Dimension: 1/2”to 12” / DN15 ~ DN300, applied to the stainless steel pipeline system.
Surface finish: mirror polished, descaled finish
Application: Food, Brewery, Beverage, Dairy, Pharmaceutical, Biopharm, Fine Chemical, Personal Care Industries etc
Packaging: Packed in carton box firstly, then in wooden case
