I.    Safety Instruction

1. For security, please read instructions carefully before initial operation; making sure that the power is off before connection.
2. Please clear the memory before initial operation. (Ref: Erasing ALL learned/memorized Transmitters）
3. Do not learn the remote control when motor is operating in order to avoid mis-operation.
4. The received signal may be interfered by other communication devices. (e.g. the wireless control system with the same frequency range)
5. It is forbidden to control the high-risk coefficient equipment / system. (e.g. cranes)
6. It is used only for the manual remote control and wireless control equipment / system which must not endanger life or property during running failure, or its security risks have been eliminated
7. It should be applied in dry indoor place or in the electric appliance place.
8. If connected wire is too long , the receiver may work unstable

II. Technical parameters

 1. Working voltage:12-24VAC/DC
 2. Temperature range:-20℃ to 60℃
 3. Working frequency:433.92MHz
 4. Stored transmitters: Rolling code 30
 5. Relay contact load capacity:：1A,30V DC
