Product features

1. Imported chips are preferred. It has excellent luminous flux maintenance rate and high luminous efficiency. The surface mount technology SMT is adopted to greatly improve the thermal conductivity.

2. Using constant current drive, the power supply has short-circuit and over-voltage protection functions, and has excellent electromagnetic compatibility, which will not cause any interference to other electrical appliances and power transmission networks.

3. The three-cavity independent structure is carefully designed to ensure the stable operation of various electronic components, and the heat dissipation duct with air diversion structure is carefully designed to ensure the service life of the LED light source.

4. The whole lamp adopts IIC-class explosion-proof structure and IP65 protection grade, with excellent explosion-proof protection performance, and adopts high borosilicate tempered glass, which can withstand high-energy impact.


Scope of application

1. It is widely used in places with high protection requirements, corrosive explosive gas and non-conductive dust.

2. It is suitable for IIA IIB explosive gas mixture, temperature group T1-T6 zone 1 and zone 2, and non-conductive combustible dust environment in zone 20, 21 and 22. It is suitable for petroleum exploration, chemical industry and military industry. , Ships, electronics and other dangerous environments and petroleum platforms, tankers and other explosion-proof work lighting.
