Full 358 Anti-climb Fence Mesh Machine Line insist of :
- Anti-climp fence welding machine
-Wire straighter&cutter
-Fence bender
Anti-climp fence welding machine
Anti-climb fence welding machine also called security fence machine,it is used to mae fence mesh,road mesh,reinforcing mesh,shelf,explosion-proof wall etc.
1.This machine adopts synchronous control technique. The cent-control and welding time are composed of PLC program system.
2.The input front-panel is touch screen , the operate is more intelligent and reasonable
3.The line wire and the cross wire are pre-straight and pre-cut.
4.Wire mesh panel be pulled by the stepper motor automatically
4.The cross wire feeding from the hopper automatically
5. The transformer adopts specical ones to make the welding spot uniform.
Program |
SN-HL-358-1500 |
SN-HL-358-2000 |
SN-HL-358-2500 | |
|
Wire diameter |
3.0-6.0mm | 3.0-6.0mm | 3.0-6.0mm |
|
Max mesh width | ≤1500 | ≤2000 | ≤2500 |
|
Number of electrodes | 31 | 41 | 48 |
|
Mesh Length | 0.7-6.0m | 0.7-6.0m | 0.7-6.0m |
|
Cross wire spacing | 12.7-300mm | 12.7-300mm | 12.7-300mm |
|
Line wire spacing | 76.2-300mm | 76.2-300mm | 76.2-300mm |
|
Electric capacity | As request | As request | As request |
|
Work strokes | 40-60/min | 40-60/min | 40-60/min |
|
Control System | PLC programmable controller | PLC programmable controller | PLC programmable controller |
Wire straighter&cutter
This machine mainly consists of tray bar rack, straightening rack,tractor cutting device, base support, and motor rotation facility. This machine is applicable to straighten and cut all types of metal steel wire, stainless steel wire, aluminum wire, and cold-drawing wire.
Wire diameter:2.5-5.0mm
Cutting length: as request.
Fence bender
Wire Mesh Fence Curver Bending Machine use for bend the curver on fence pannel.
It also can be bend metal sheet.
| Medel | Nominal Force | Width | Working Stroke | Motor Power | Length | Width | Height | Weight |
| SK60/2500MM | 60 T | 2500mm | 120mm | 7.5 kw | 3340 | 1000 | 2100 | 4 |
| SK80/2500MM | 80 T | 2500mm | 120mm | 7.5 kw | 3340 | 1000 | 2100 | 5 |
| SK100/2500MM | 100 T | 2500mm | 120mm | 11 kw | 3340 | 1000 | 2100 | 6.1 |
| SK160/2500MM | 160 T | 2500mm | 150mm | 15 kw | 3500 | 1100 | 2300 | 8.5 |
| SK220/2500MM | 200 T | 2500mm | 150mm | 18.5 kw | 3500 | 1200 | 2400 | 12 |
The fence is designed to make it very difficult to cut through the panel with simple hand tools. With wire thickness of 4mm and spacing of 75mm x 12.5mm, intruders can never cut off the fence.
Anti climb fence is widely used by reputable Real Estate Developers, Industrial Factories, Engineering Firms, Farms owners, Government Sectors
Products are widely used in electricity distribution sites, prison perimeter areas, airports, warehousing facilities & wildlife sanctuaries,etc.
