Composite StrappingCord strapGALVANISED BUCKLESWire Buckles
L/CT/TD/PWestern UnionPaypalMoney GramOthers
The high tensile galvanised buckles are engineered to perform with the highest joint efficiency in the strapping industry.
Steel Wire Buckle (composite strapping buckle) are made by high quality carbon steel,it superior holding power in all weather conditions,It provides maximum joint efficiency for the highest system strength.The size from 13mm to 50mm,diameter from 3.0mm to 8.0mm,The breaking strength from 453kg to 4500kg,it is suitable for polyester cord strapping and woven lashing strap.
Material: Metal, Carbon Steel
Size: 13mm 16mm 19mm 25mm 32mm 38mm 50mm
Diameter: 3.0mm- 8.0mm
Work Load: 353kg-4500kg
Surface: Galvanized or Phosphated
Suitable Strap: for 13mm-50mm composite cord strap,woven cord strapping, hot melt strapping,plastice strapping
Galvanized Strapping Buckle 19mm
| Product Model | Width(mm/inch) | Diameter(mm) | Pcs/Box | Broken Load (kg) | Type |
| KYA-30 | 13 or 1/2" | 3.3 | 1000 | 453 | Galvanized Or Phosphating |
| KYA-35 | 16 or 5/8" | 3.5 | 1000 | 659 | |
| KYA-40 | 19 or 3/4" | 4.0 | 1000 | 855 | |
| KYA-50 | 25 or 1" | 5.0 | 500 | 1237 | |
| KYA-60 | 25 or 1" | 6.0 | 500 | 1557 | |
| KYA-70 | 32 or 5/4" | 7.0 | 250 | 2439 | |
| KYA-70A | 38 or 3/2" | 7.0 | 150 | 3596 | |
| KYA-80 | 50 or 2" | 8.0 | 100 | 4500 |
1. Galvanized buckles are protected from corrosion, sea water and other climatic threats.
2. They are designed for easy threading and deliver the ultimate in high load performance.
3. They have outstanding slip resistance due to its self-lock feature in order to maximize holding power.
4. The production of all the wire buckles is fully automatic in our factory, which makes them very cost-effective.
5. Reliable quality, through the SGS TUV testing.
6. Easy operation , with the aid of strap tensioner,.
7. Can be used for large objects binding , such as: wood, steel, stone, etc.
8. Application range is wide, can be applied to a variety of types of packing strap.
Suitable Strap: for 13mm-50mm composite cord strap,woven cord strapping, hot melt strapping,plastice strapping.
Container Load,Steel Tube,Aluminum Ingot,Motor,Wood,Pallet,Mining and Resources,Oil and Gas,Offshore and Marine,Freight Forwarding,Logistics Packing and other packing.
How to use wire buckles for plastic strapping?
