As one of the important components of the whole industry chain serving the low temperature industry, Honto brand cryogenic storage tank products can provide different insulation methods for the industry users at present, such as ordinary stacking insulation, vacuum powder insulation, high vacuum multilayer insulation, etc.; from 3.8m3 to 50000m3, various fixed pressure vessels and fixed atmospheric pressure vessels of different volumes.
Through 20 years of technology accumulation, Hongtu series of cryogenic storage tank products and business scale have been in the forefront of the country. It has the overall solutions in various fields from storage to industrial application for industry users, and fully meets the needs of industry users.
LNG CRYOGENIC TANK FOR GASIFICATION STATION | |||||||
Item | Geometric Vlume (m3) | Working Pressure (MPa) | Dimension Vertical:(DxH)mm Horizontal: (LxWxH)mm | Weight (kg) | Filling Weight (kg) | Insulation Method | Type |
1 | 55.56 | 0.8 | Φ3020x13520 | 17900 | 21300 | Pearlite Insulation | Vertical |
2 | 55.56 | 0.8 | 13200x3020x3370 | 17330 | 21300 | Pearlite Insulation | Horizontal |
3 | 60 | 0.8 | Φ3020x14375 | 20700 | 23004 | Pearlite Insulation | Vertical |
4 | 60 | 0.8 | 14200x3020x3370 | 18150 | 23004 | Pearlite Insulation | Horizontal |
5 | 100 | 0.8 | Φ3624x16350 | 35400 | 38340 | Pearlite Insulation | Vertical |
6 | 111.1 | 0.8 | Φ3624x17940 | 37000 | 42600 | Pearlite Insulation | Vertical |
7 | 150 | 0.8 | Φ3824x21087 | 48500 | 57510 | Pearlite Insulation | Vertical |
8 | 166.67 | 0.8 | Φ3824x23160 | 51800 | 63900 | Pearlite Insulation | Vertical |
LNG CRYOGENIC TANK FOR REFUELING STATION | |||||||
Item | Geometirc Volume (m3) | Working Pressure (MPa) | Dimension Vertical:(DxH)mm Horizontal:(LxWxH)mm | Weight (kg) | Filling Weight (kg) | Insulation Method | Type |
1 | 60 | 1.2 | 13550x3016x3392 | 20660 | 23004 | Pearlite Insulation | Horizontal |
2 | 60 | 1.2 | Φ3200x13823 | 18780 | 23004 | Pearlite Insulation | Vertical |
3 | 60 | 1.2 | 14200x3020x3370 | 17000 | 23004 | Multi-layer High Vacuum Insulation | Horizontal |
4 | 60 | 1.2 | Φ3200x14275 | 19750 | 23004 | Multi-layer High Vacuum Insulation | Vertical |
