The LNG ISO Tank Container adpots GB standard and ASME standard, and has special equipment manufacturing supervision and inspection certificate, China Classification Society and BV classification society certificate, which can meet the requirements of road, sea, railway and intermodal multi-model transportation.
Design code: NB/T47059, TSG R0005, ASME BPVC.Ⅷ.1, RID/ADR, IMDG T75, UIC, DOT49CFR, CSC, ISO1496/3
Dimension: (L*W*H): 12192x2438x2591(mm)
Maximum Allowable Working Pressure: 0.79 MPa(GB)/0.83 MPa(ASME)
Capacity: 45.5m3
Insulation Type: High Vacuum Multilayer Insulation
ASME Code LNG ISO Tank Container | ||
20ft | 40ft | |
Inner Tank Material | S30408/SA240 304 | S30408/SA240 304 |
Outer Tank Material | Q345R | Q345R |
Design Capacity | 20.2m3 | 45.5m3 |
Medium | LNG | LNG |
Tare Mass | 7750KG | 11807KG |
Max. Gross Mass | 360000KG | 30480KG |
Tank Outline Dimension( ID * H * L) | 6058*2438*2591mm | 12192*2438*2591mm |
Design pressure | 1.8 MPa | 0.79 MPa |
Allowable Working pressure | 1.8MPa | 0.79 MPa |
Working Temperature | -196~50 ℃ | -196~50 ℃ |
Design Temperature | 50 ℃ | 50 ℃ |
Corrosion Allowance | 0mm | 0mm |
Insulation | High Vacuum Multi-layer Insulation | High Vacuum Multi-layer Insulation |
