By adopting imported polymer microporous separator and high density gel electrolyte, the advantage of TIANJIAO is more outstanding: wider operating temperature range, stronger recovery

ability after over-discharging,longer cycle-life at deep discharging.

1.Patent structure: The use of convenient wire type structure for connection (patentNo z 200720045887.1 and ZL 200720037066.3), helps achieve a true underground installaion, avoidthe pole corrosion.

2. Recovery performance: The adoption of high-quality alloys and lead paste formulations makes alow self-discharge rate, good deep discharge tolerance, and strong recover capability.

3. Charging efficiency: The Usage of raw material of low resistance and advanced process makes asmall internal resistance and strong small current charge acceptance.

4. High and low temperature tolerance: A wide temperature range of -50~65C , suitable for indoorand outdoor use in varies environments.

5. Long cycle-ife: By using corrosion-resistan alloy and high density of quality nanoscale fumedsilica gel electrolyte, the product is corrosion -resistant, free of electrolyte stratification. The design lifecan reach to 18 years.

6. Environmental-friendly.Cadmium(Cd), which is poisonous and not easy to recycle, is not existing.It is free of acid leakage of gel electrolyte. All guarantee batteries can operate in safety andenvironmental protection.

Characteristic

Feature
_{1). Absorbent Glass Mat (AGM) technology for superior performance
2). Valve regulated, spill proof construction allows safe peration in any position
3). Power/volume ratio yielding unrivaled energy density
4). Rugged impact resistant ABS case and cover (UL94-HB)
5). Integrated ABS carrying handles for ease of movement
6). U.L. CE. IEC. SGS. RoHS. ISO9001. ISO14001. OHSAS18001-2007 recognized
7). Maintenance-free operation - no addition of water to the electrolyte is required.
8). Wide range of operating temperatures with temperature compensated charging.
9). Computer designed lead, calcium tin alloy grid for high power density.
10). Extended service life due to low self-discharge levels.}

APPLICATION

1). Electrolyte: Be immobilized in the cell through the use of fumed silica gel agent or absorbed in the separators and plates.

The cells shall have no residual free or bulk liquid electrolyte.
2). Lead : high purity lead, >99.996%
3). Separators: Made of fiberglass. Be porous to electrolyte but electrically insulating.
4). Container & Cover: containers and covers shall be made of a high impact, flame-retardant ABS plastic
5). Terminal: Terminal posts shall be cast in lead or lead alloy and have a copper core insert.
6). Valve: The valve operate at the pressure limits specified. The valve will not allow ingress of outside air into the unit.

COMPANY PROFILE

Huafu High Technology Energy Storage Co., Ltd is a leader in the battery industry for energy storage in China, manufacturer ranks NO. 1 in sales of GEL battery in Chinese market, with more than 30 years experience in producing and exporting environmental friendly rechargeable energy storage battery, motive power battery, reserve power battery and lithium battery, including AGM sealed lead-acid (SLA) Battery, deep cycle solar gel battery, long life OPzV Battery, long life lead-carbon battery, front terminal battery, energy storage lithium battery, power lithium battery, telecommunication lithium battery.

HUAFU - the leader in the storage battery industry
HUAFU - the leader in scientific and technological innovation in the energy storage industry.

FAQ

Q1: Are you a manufacturer or a trader?

A: Our company is a professional battery manufacturer in China. The factory located in Yangzhou city,Jiangsu province.We have more than 25 years experience in battery industry.


Q2: What kinds of battery will you provide?
A: We can provide full range of 2v/12v gel and lead acid battery, lead carbon battery ,EV battery, tubular battery, lithium-ion battery and so on.

Q3: Can I print my logo on the battery?
A: Yes. We can provide OEM and ODM service. We can print your picture or logo on the battery and box.

Q4: Can your battery meet CE requirements?
A: Yes, our battery meet CE, UL, ISO9001, ROHS, can be exported to almost every country.

Q5: Do you test all the batteries before delivery?
A: Yes, we have 100% test before delivery.

Q6: Do you have after-sales service?
A: Yes, battery with quality problems will be changed as long as the battery still under warranty period.

Q7: If I place an order now, how long it will takes you to arrange the delivery?
If we have finished batteries,usually it will takes 10-15 days to arrange the shipment. Otherwise, it will takes more than 15 days cause we need to arrange the production.
