Industrial Quality PCI Approved ATM Keyboard

Industrial Quality PCI Approved ATM Keyboard

Sunson Tech SE8098B is an encrypting PIN pad(EPP) for indoor and outdoor use, offering manufacturers another form factor for integration. Optimized for use in self-service kiosks, ATMs and self-payment gas pumps, the ruggedized design of this EPP is built to withstand the most severe fraudulent attacks while complying with payment security standards on the back end.
For ATM applications, Sunson Tech offers an optional XFS Service provider for easy integration.

  Features Glance

• PCI 3.0 approved EPP;

• Standard USB interface or RJ45-RS232 output;

• The key uses precise casting technology and unique inlay technology, which guarantee the perfect tactile.

• Professional performance of water proof, dust proof, vandalism resistance, anti-drill, anti reveal, anti replacement etc.

• The key, program and any sensitive self-destroy mechanism against illegal dismantle.

• Support DES/TripleDES algorithm,support EPP suit software;

• Support RSA algorithm (max 4 0 9 6 b i t),support AES (on request)

• Fast computing speed, the computing time is less tan 2s for 1024bits with 3DES algorithm;

• Support multi level key system, max 688 levels.

Mechanical performance

• Front panel and key:high qualified stainless steel

• Key lifespan: more than 2 million operations

• Key pressure:2~3N

• Key stroke:0.45mm

• Key legends:laser etching and strong painting.

• Actuation force:50g

• Input details:10 digits keys,6 function keys

• extendable:2 pcs of 1*4 functional keypad

• data protection:data will be kept for more than 8 years against power-off.

Electronic performance

• Interface:RJ45-RS232 interface,baud rate:9600,8 data bit, 1 stop bit and no check parity.

     Standard USB2.0 interface (USB 1.1 is compatible)

• Voltage: 5.0V±10%

• consumption: ≤0.5W(dynamic),≤0.2W(static)

• reliability: MTBF>20000H, MTTR<30min

Environmental Requirement

• Working temperature:-25oC~65oC

• Storage temperature:-40oC~85oC

• Relative humidity:30~90%RH

• Air pressure :50~100Kpa

• Protect level:IP65(static)/IP54(dynamic)

Algorithm standard

• DES,3DES:ANSI X3.92,ANSI X9.52

• PIN operation:ANSI X9.8(ISO9564.0,ISO9564.1,ISO9564.3),IBM3624

• MAC operation:ANSI X9.9,ANSI X9.19

• Security standard:ISO13491

• Encrypting and decrypting speed:<0.1S(8 bits DES)

Sunson Profile

FAQ
Q1: Can you customize the metal keyboard or keypad?
A1: Yes, we can customize language & layout for you freely.
      If you have big order need customized size, surface etc., tailor made service is also available.

Q2: How long is the warranty for your products?
A2: The standard warranty is 1 year from the date of delivery, but can extended if extra cost paid.

Q3: Can you provide free sample?
A3: We can provide you sample for approval, but there is a sample charge, which can be returned when your order qty reaches a certain number.

Q4: What is EPP?
A4: EPP is short of Encrypted PIN Pad, an Encrypting PIN Pad is an apparatus for encrypting an identifier such as a PIN entered on a keypad. These are used in Automated teller machines or self-service kiosk to ensure that the unencrypted PIN is not stored or transmitted anywhere in the rest of the system and thus cannot be revealed accidentally or through manipulations of the system.

Q5: What kind of support can you provide on software development?
A5: We can provide you complete SDK for you to development software, we also have a strong engineers and customer service team to provide you technical support.
