Small Metallic Keypad Encrypting Pinpad For Compact Kiosk

ID:20102024465

Category: Electronics and Communications Computer & Accessories

FOB Price:US$ 160.000 / Piece(s)

MOQ:10.00 Piece(s)

Product Keywords:

Long Lifespan EPPMetal Encryption PinpadADA Compliant EPPPayment Device KeypadPCI Braille KeypadPin Input Device EPPPayment Kiosk EppRS232 Pin EppSmall Encrypting PinpadCompact Kiosk Pinpad

Payment Method:

L/CT/TD/PWestern Union

Product Category

Electronics and Communications > Computer & Accessories

Trademark

Sunson or OEM

Product Package

Carton Package with Cushion Material

Specification

74*74*1.5mm

Place of Origin

China

Port

Shenzhen

Small Metallic Keypad Encrypting Pinpad For Compact Kiosk

This Small Metallic Keypad Encrypting Pinpad For Compact Kiosk is PCI 4 approved Encrypting Pin Pad, with the most thin and compact outlook, it is suitable for portable payment devices well.

Features:

1) PCI 4.0 EPP
2) China Union Pay Approved EPP
3) Compact design with thickness of 20.1mm only
4) Support DES/TriDes, AES
5) Support RSA and RKL
6) Support DUKPT (on erquest)
7) Equipped with HW removal switch
8) One click SDK for WOSA platform
9) Fonts on button can be customized

Specifications:

1) One of the most compact PCI EPP

2) PCI 4.0 and China Union Pay approved EPP

3) Material: Stainless steel

4) ADA compliant with standard braille dots (optional)

5) Key Operation time: more than 2 million times

6) key letter technology: Laser engrave

7) Support DES/Tri-Des

8) Support max 4096 bit RSA algorithm

9) Support multi-class key system

Electronic features:
1) Interface:mini USB
2) mini USB to USB type A
3) Voltage: 5.0V±10%
4) Consumption: ≤0.5W(dynamic) ≤0.2W(static)
5) Reliability:MTBF>20000H MTTR<30min
6) Data protection:data will be kept for more than 8 years against power-off

Support Algorithm:

1) RSA: support more than 2048 bit

2) DES,3DES:ANSI X3.92,ANSI X9.52

3) PIN operation:ANSI X9.8(ISO9564.0,ISO9564.1,ISO9564.3),IBM3624

4) MAC operation:ANSI X9.9,ANSI X9.19

5) Security standard:ISO13491

6) Encrypting and decrypting speed:<0.1S(8 bits DES)

Applications:

1) Cash-ref terminals:such as ATM,ADM,CDM,CRS etc

2) Unattended Payment Terminals: such as UPT in gas station

3) Self-service terminals: such as E-bank terminal, ticket vendors, vendor, auto gas dispenser, etc.

Sunson Profile

FAQ

Q1: Can you customize the metal keyboard or keypad?
A1: Yes, we can customize language & layout for you freely.
If you have big order need customized size, surface etc., tailor made service is also available.

Q2: How long is the warranty for your products?
A2: The standard warranty is 1 year from the date of delivery, but can extended if extra cost paid.

Q3: Can you provide free sample?
A3: We can provide you sample for approval, but there is a sample charge, which can be returned when your order qty reaches a certain number.

Q4: How is your after sales service?
A4: Our well-trained engineers can provide you any technical support in time.
Our sales persons are also available at 24/7 on mobile phone, email etc.

Q5: Are you trading company or manufacturer?
A5: We are a manufacturer, with 17 years' experience in developing, designing and producing various metal keyboards & pin pads.
