ZSHOF/ZDROF Series fluorine lined ball valve is two-pieces full bore floating ball valve. The body and ball lined with F46 or PFA，and used in all kinds of acid, alkali, salt and other corrosive medium. corrosive service.
FEATURE:
1、 Lined technologies offer a number of advantage, such as resistance to corrosion, while providing high performance, and preventing in-line leakage and fugitive emissions.
2、 Anti-blowout stem assembly prevents stem blowout even in the event of top works disassembly；
3、 Separate ball/stem connection greatly reduces side loading, thus extending stem seal life;
4、 Positive stem seal. PTFE chevron packing provides stem seal integrity while maintaining low turning torque;
5、 Lining securely locked into the body by “T” slots and locking grooves; completely encapsulated ball and stem;
Specification
DN(mm) | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 | 250 |
Rated KV | 20 | 38 | 72 | 110 | 170 | 270 | 380 | 510 | 940 | 1400 | 2200 | 3500 | 5000 |
PN (MPa) | 1.0、1.6、150lb | ||||||||||||
Flow Characteristic | Quick Open | ||||||||||||
Rated Angle（°） | 0±4°～90±4° | ||||||||||||
Temperature（℃） | -30~150 | ||||||||||||
Leakage Class | VI | ||||||||||||
Air Supply Ps（MPa） | 0.4～0.6 | ||||||||||||
Voltage | 220V.AC 50Hz OR 380V.AC 50Hz | ||||||||||||
Flange Connection | RF | ||||||||||||
Actuator
Type | Pneumatic Piston Actuator | Electric Actuator | |
Modle | SR | DA | Refer to actuator manufacters’ Spec. |
Action | Single Acting | Double Acting | |
Application | Shutoff | ||
Connection | G1/8”、 G1/4”、 G1/2” | Refer to actuator manufacters’ Spec. | |
Rated Angle | 90° | ||
Direct Action | Air to Close | ||
Reaction | Air to Open | ||
Temperature | -40~80℃ | ||
Accessories | Relief valve, solenoid valve, limit switch, handwheel, Speed controller | ||
Torque Table(N.m)
DN(mm) | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 | 250 | |
Torque N.m | PN16 | 8 | 10 | 12 | 20 | 32 | 40 | 65 | 100 | 140 | 260 | 450 | 750 | 1200 |
Note: The above torque value is just for reference.
1.Q: Are you a manufacturer or trading company ?
A: we are valve manufacturer and factory ,and not trading company.
2. Q: Do you have agent or representative abroad?
A: We have agent in Russia and Kuwait and so on.
3. Q: What's your product range?
A: We can produce Control Valve, Butterfly Valve, Self Operated Valve,Ball Valve, Actuator and Air cylinder etc.
4. Q: Is there any stock in your factory? and how about your lead time?
A: We stock valves with normal sizes. The lead time depends on your quantity,generally 30-60 days.
5. Q: Which countries do you export to ?
A: We export directly to vast majority of countries in the world.
6. Q: What certificates will you provide ?
A: We can provide API-6D/TRCU010 and TRCU certificates/ECM/API STD 607/Certificate of Quality System Approval /SIL/DUNS/ISO9001......
7. Q : How do you control the quality of the product?
A: Adheres to strict quality control procedures that begin with product design and carry through to the end of the production process using state-of-the-art quality control equipment
8.Q : How to ship the goods?
A: We can arrange the shipment for your, you just need to tell us your convenient seaport or airport; we can help to ship the goods by your agent as well.
