ceiling machineU baffleroll forming machine
Machine for above drawing Included:
Vertical decoiler *1
Feeding guide system*1
Mainly forming system*1
Servo hydraulic cutting *1
Hydraulic station with cool fan.*1
Full line control system*1
Ramp receiving table *1
Working Process
Parameters and specification
1.Mainly forming system
Main power: 7.5kw
Forming speed: 30m/min
Shaft material and diameters: #45 steel and 60mm (Made fi the steel for cementation)
Roller material:: Cr12 with well heat treatment
Forming Steps: 19 steps for forming
Driven: chain and gear
2.Electronic part
Inverter：Delta （Taiwan）
Encoder: Japan Omron(Japan)
Servo motor: shanghai Zoncn
low-voltage apparatus CHNT (China)
Voltage: 380V 50Hz 3 phase(depends on the customer)
PLC(zoncn) control and touching screen . PLC(zoncn)
3.Cutting servo motor control without stop
Cutting Power: 1.5 kw
Hydraulic station power:4 kw
4.Ramp receiving table
